Modern RV Garage house Plan with CAD Designs and Floor Plans
Explore this RV garage house design with modern architecture, detailed CAD blueprints, and functional floor plans. Perfect for workshops and vehicle storage.
Original price was: $1,150.56.$651.99Current price is: $651.99.
999 in stock
| Width | 40'-0" |
|---|---|
| Depth | 42'-0" |
| Htd SF | |
| Unhtd SF | |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| Htd SF Range | |
| Unhtd SF Range | |
| # Garage Bays | |
| Architectural Styles | |
| Indoor Features | |
| Garage Features | |
| Ceiling Features | |
| Structure Type | |
| Exterior Material | |
| # Front Elevations | |
| Depth Range | |
| Width Range | |
| After Build Photos |
Modern RV Garage House Plan with CAD Designs and Functional Workshop
Explore this modern RV garage house plan with 410 heated sq. ft., 2, 640 unheated sq. ft., and workshop space—includes CAD blueprints, high ceilings, and flexible layouts.
This modern RV garage house plan offers the perfect combination of vehicle storage, workshop functionality, and clean architectural design. Created with simplicity and utility in mind, it’s ideal for car enthusiasts, DIYers, and families needing extra garage capacity.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 410 sq. ft. over two floors including a versatile loft.
- Unheated extras: 2, 640 sq. ft. dedicated to spacious RV bays, standard vehicle storage, and a workshop zone.
Bedrooms & Bathrooms
- This plan is focused on garage and workspace functionality—residential space can be added if desired during modifications.
- Optional layouts available for bathroom additions or future upgrades.
Interior Highlights
- 18-foot ceilings in the garage area for RV, boat, or trailer clearance.
- Workshop space perfect for tools, storage, or professional projects. See more garage workshops.
- Loft area adds flexible space—ideal for storage, office, or a compact apartment conversion.
- Slab foundation ensures easy, cost-effective construction.
Outdoor Living Features
- Simple barn-style exterior with durable siding for modern curb appeal.
- Customizable roofline and door heights to fit your specific RV or vehicle size.
Architectural Style: Modern Barn-Style Utility
This layout blends clean lines and minimalist materials in a barn-style design that prioritizes storage, function, and low-maintenance exteriors—ideal for narrow or deep lots.
Included Benefits with Every Plan
- CAD + PDF Files: Easily editable, printable, and ready to build.
- Unlimited Build License: Build once—or 100 times—with no extra fees.
- Free Foundation Changes: Swap between slab, crawlspace, or basement.
- Structural Engineering Included: Code-compliant and professionally stamped.
- Lower Modification Costs: Up to 50% less than competitors.
- View Before You Buy: See every sheet in advance.
Similar Collections You Might Love
- Garage & Vehicle Storage Plans
- Garage Workshop Plans
- Detached Garage Plans
- Barndominium House Plans
- House Plans with Large Garage
Frequently Asked Questions
What’s included with this house plan? All plans include editable CAD files, printable PDFs, a lifetime build license, structural engineering, and the option for free foundation changes.
Can this be converted into a full residence? Yes! The loft or main garage space can be modified to include living quarters. Contact us for custom quotes.
Is the garage height suitable for Class A RVs? Absolutely. The 18’ ceiling easily accommodates Class A RVs, trailers, boats, and tall vehicles.
What kind of foundation is it built on? This plan uses a durable slab foundation, but we can modify it to crawlspace or basement if preferred.
Can I preview the entire blueprint? Yes! Preview every sheet online before you buy.
Learn More About the Garage + Utility Design Approach
Explore how garage-centric plans are reshaping the way Americans store and work at home in this detailed guide from ArchDaily.
Start Building Your Dream Garage Today
Ready to get started or need customizations? Reach out to our team at [email protected] or send us a message here.
Your future garage workshop starts with a plan designed for maximum function—customize it and build with confidence!
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
Unless shown, the plan will not have the electrical layout. We can provide electrical layouts at $100 for 0-1499 sq. ft. home plans and $200 for 1500+ sq. ft. plans. This includes details such as recessed lights, fan/lights, switches, outlets, cable tv & telephone locations, exterior flood light locations, weather proof outlets, heat/vent/light locations…etc. After you receive the electrical layouts, review and mark any desired changes. Take a picture and we will make any and all modifications at NO EXTRA CHARGE. And do not worry if you need to go back and forth a few times. This is inclusive of the $200 fee. Turnaround time averages 2 days.
