Stylish 2-Bedroom Townhome Floor Plan with CAD Blueprint Design
Discover a stylish 2-bedroom, 1.5-bath townhome with an open layout, modern CAD blueprints, and cozy architectural details—perfect for compact and comfortable living.
This modern townhome floor plan offers a perfect mix of charm and functionality. Designed for everyday convenience, it balances smart space planning with timeless suburban appeal.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 1, 965 sq. ft. over two levels.
- Unheated extras: Patios and porches expand your outdoor living experience.
Bedrooms & Bathrooms
- 2 comfortable bedrooms located on the first floor for easy access and privacy.
- 1 full bath and 1 half bath strategically placed for convenience and guest use.
Interior Highlights
- Open floor plan creates a seamless flow between kitchen, dining, and living areas. View open layouts.
- Kitchen island offers a space for meal prep, storage, and casual dining. Explore kitchen island plans.
- Upstairs laundry room keeps laundry tasks tucked away and easy to manage.
- Great Room serves as the central gathering space with room to entertain or relax.
Garage & Storage Details
- Garage Bays: Optional attached garage can be customized for 1–2 cars.
- Garage Type: Attached for easy access.
- Storage: Ample closet space and cabinetry included throughout the plan.
Outdoor Living Features
- Front porch and rear patio offer relaxing outdoor options in a compact footprint.
- Exterior finishes include a mix of brick and siding for classic, low-maintenance curb appeal.
Architectural Style: Modern Suburban with Traditional Accents
This design blends modern efficiency with warm suburban style—ideal for small families or professionals. Learn more about the modern suburban style or explore its influence on ArchDaily.
Bonus Features
- Dual-level layout with bedrooms below and living above for privacy and flow.
- Flexibility to convert one bedroom into an office, den, or guest room.
- Designed with narrow lots in mind—efficient use of space without sacrificing comfort.
Included Benefits with Every Plan
- CAD + PDF Files: Editable blueprints ready for modification and permit use.
- Unlimited Build License: Build as many times as you like without extra fees.
- Free Foundation Changes: Easily adapt to slab, crawlspace, or basement foundations. See how it works.
- Structural Engineering Included: Professionally stamped and code-compliant designs.
- Lower Modification Costs: Save 50% or more compared to competitors.
- View Before You Buy: See full blueprint previews before purchasing.
