11-1217 GARAGE PLAN – Compact House Garage Plan with CAD Blueprint Designs
Explore this compact house garage plan with CAD blueprint designs featuring 3 spacious bays, brick exterior, and affordable solutions for narrow lots.
Compact House Garage Plan with CAD Blueprint Designs
Explore this compact house garage plan with 1,087 heated sq. ft., 3 garage bays, and brick architecture—perfect for narrow lots and affordable builds.
This compact garage house plan offers a perfect mix of utility and style. Designed for budget-conscious builders, it delivers functional design and architectural appeal, even on narrow lots.
Key Features of the Garage Plan
Living Areas – Heated & Unheated
- Heated area: 1,087 sq. ft. on a single level.
- Unheated extras: 1,130 sq. ft. of garage space and workshop potential.
Bedrooms & Bathrooms
- No bedrooms are included in this design—it’s strictly focused on garage and workspace functionality.
- Optional utility sink or half bath can be added during customization if needed.
Interior Highlights
- Workshop space ideal for hobbies, storage, or professional projects.
- Optional insulation and HVAC allow the heated area to be used year-round.
- Storage room included for seasonal gear, tools, or household overflow.
- 9-foot ceilings enhance accessibility and airflow. Explore functional layouts.
Garage & Storage Details
- Garage Bays: 3-car capacity with front entry.
- Garage Type: Attached or freestanding configurations available.
- Storage: Dedicated rear storage room and overhead space options.
Outdoor Living Features
- Brick exterior provides long-term durability and visual appeal.
- Compact footprint fits on lots under 40 feet wide. See more narrow lot designs.
Architectural Style: Brick Garage with Modern Utility
This garage plan uses classic brick materials paired with efficient layout design—ideal for homeowners who want durability without sacrificing style. Learn more about our garage plan designs or explore small-space innovation at ArchDaily.
Bonus Features
- Slab foundation offers affordability and structural simplicity.
- Optional attic truss system allows for upper-level storage or future conversion.
- Workshop-ready layout caters to both hobbyists and professionals.
Included Benefits with Every Plan
- CAD + PDF Files: Editable and printable for quick start.
- Unlimited Build License: Construct the plan as many times as needed.
- Free Foundation Changes: Choose from slab, crawlspace, or basement options. Learn more.
- Structural Engineering Included: Stamped and code-compliant designs.
- Lower Modification Costs: Up to 50% less than the competition.
- View Before You Buy: Preview every sheet first.
Similar Collections You Might Love
- Detached Garage Plans
- Garage Workshop Plans
- RV Garage Plans
- Golf Cart Garage Plans
- Side-Load Garage House Plans
Frequently Asked Questions
What’s included with this garage plan? You’ll receive CAD files, PDF blueprints, unlimited build rights, free foundation changes, and structural engineering with your purchase.
Can I convert part of this garage into living space? Absolutely. The heated portion is already ideal for a future studio, office, or bonus room.
Will this fit on a narrow urban lot? Yes, it was designed for compact lots under 40 feet wide, maximizing functionality.
Can I add a bathroom or utility hookup? Yes. All our plans are fully customizable—just ask us for a modification quote.
Can I use this as a standalone garage or in addition to a house? Both options are available—it works as a primary detached garage or an accessory structure.
Start Building Your Dream Garage Today
Have questions or want to personalize your plan? Contact our expert team at support@myhomefloorplans.com or reach out here.
Your future garage starts with the right blueprint—customize it and build with confidence today!
Original price was: $2,070.56.$1,134.99Current price is: $1,134.99.
999 in stock
| Width | 28'-6" |
|---|---|
| Depth | 46'-6" |
| Htd SF | |
| Unhtd SF | |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| Htd SF Range | |
| Unhtd SF Range | |
| # Garage Bays | |
| Architectural Styles | |
| Garage Features | |
| Ceiling Features | |
| Structure Type | |
| Exterior Material | |
| # Front Elevations | |
| Depth Range | |
| Width Range | |
| After Build Photos |
Carl Higgins – December 14, 2024
Clear porch column sizing guide.
Please log in to generate images.
11-1217 GARAGE PLAN – Compact House Garage Plan with CAD Blueprint Designs
- BOTH a PDF and CAD file (sent to the email provided/a copy of the downloadable files will be in your account here)
- PDF – Easily printable at any local print shop
- CAD Files – Delivered in AutoCAD format. Required for structural engineering and very helpful for modifications.
- Structural Engineering – Included with every plan unless not shown in the product images. Very helpful and reduces engineering time dramatically for any state. *All plans must be approved by engineer licensed in state of build*
Disclaimer
Verify dimensions, square footage, and description against product images before purchase. Currently, most attributes were extracted with AI and have not been manually reviewed.
My Home Floor Plans, Inc. does not assume liability for any deviations in the plans. All information must be confirmed by your contractor prior to construction. Dimensions govern over scale.
