11-1613 CABANA – Compact House Blueprint with CAD Designs & Open Floor Plan
Explore this cabana-style house plan with CAD designs featuring a compact 316 sq. ft. floor plan. Highlights include a covered porch, brick exterior, and slab foundation.
Compact Home Blueprint with CAD Designs & Open Floor Plan
Explore this cabana-style home plan with CAD designs featuring a compact 316 sq. ft. floor plan. Highlights include a covered porch, brick exterior, and slab foundation.
This traditional cabana-style house plan offers a perfect mix of charm and utility. Designed to be a cozy retreat, this plan provides a smart use of space and attractive design features in a small footprint.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 316 sq. ft. in a single-level layout.
- Unheated extras: Covered porch, attic storage access.
Bedrooms & Bathrooms
- No dedicated bedroom space—open design ideal for day-use or flexible guest quarters.
- 1 full bathroom, perfect for poolside convenience or guest use.
Interior Highlights
- 10-foot ceilings create a sense of openness in a compact footprint.
- Open floor plan offers seamless flow from kitchenette to lounge space. View more open layouts.
- Kitchenette with wet bar makes entertaining or refreshing easy by the pool.
- Attic space provides optional storage above.
Garage & Storage Details
- Garage Bays: None — designed for backyard or standalone poolside use.
- Garage Type: Not applicable.
- Storage: Attic area for small seasonal item storage.
Outdoor Living Features
- Large covered porch for shaded seating, lounging, or outdoor dining.
- Brick and shingle exterior creates a timeless, weather-resistant finish.
- See more covered porch house plans.
Architectural Style: Traditional Cabana
This design blends classic materials and practical elements, making it ideal as a standalone cabana, guest suite, or backyard pool house. Explore the roots of timeless outdoor structures on ArchDaily.
Bonus Features
- Wet bar setup perfect for poolside drinks or snacks.
- Flexible usage: can be customized into a guest house, art studio, or home office.
- Slab foundation included, with free changes available.
Included Benefits with Every Plan
- CAD + PDF Files: Editable and printable blueprints to get building quickly.
- Unlimited Build License: Build once—or multiple times—with no extra licensing cost.
- Free Foundation Changes: Choose between slab, crawlspace, or basement at no extra cost.
- Structural Engineering Included: Professionally stamped plans for code compliance.
- Lower Modification Costs: Save up to 50% compared to competitors.
- View Before You Buy: Preview all sheets instantly.
Similar Collections You Might Love
- Small House Plans
- Narrow Lot House Plans
- Covered Back Porch House Plans
- Cottage House Plans
- House Plans with Outdoor Kitchens
Frequently Asked Questions
Can this cabana be used as a full-time residence? It’s best suited for recreational use or as a guest suite. Modifications can help convert it for full-time use.
Are structural stamps included? Yes—all plans come with licensed structural engineering for code compliance.
Is this layout customizable? Absolutely. We offer fast and affordable edits to match your needs. Request custom changes here.
Is the foundation adaptable for my climate? Yes. Foundation changes are free and customizable based on your location.
Can I view the floor plan before buying? Of course. You can see every sheet before checkout.
Start Building Your Dream Home Today
Have questions or want to tailor this design to your space? Contact our expert team at [email protected] or reach out via our contact form.
Whether it’s for poolside luxury or backyard simplicity, this cabana plan is ready for you—customize it and bring your vision to life!
Original price was: $1,150.56.$651.99Current price is: $651.99.
999 in stock
| Width | 21'-0" |
|---|---|
| Depth | 21'-8" |
| Htd SF | |
| Unhtd SF | |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| Htd SF Range | |
| Unhtd SF Range | |
| # Garage Bays | |
| Architectural Styles | |
| Outdoor Features | |
| Kitchen Features | |
| Ceiling Features | |
| Structure Type | |
| Exterior Material | |
| # Front Elevations | |
| Depth Range | |
| Width Range | |
| After Build Photos |
Bonnie Johnson – June 11, 2025
Editable staircase detail let us rotate the stairs for basement accessArchitecturalDesigns.com would have charged hourly.
Please log in to generate images.
11-1613 CABANA – Compact House Blueprint with CAD Designs & Open Floor Plan
- BOTH a PDF and CAD file (sent to the email provided/a copy of the downloadable files will be in your account here)
- PDF – Easily printable at any local print shop
- CAD Files – Delivered in AutoCAD format. Required for structural engineering and very helpful for modifications.
- Structural Engineering – Included with every plan unless not shown in the product images. Very helpful and reduces engineering time dramatically for any state. *All plans must be approved by engineer licensed in state of build*
Disclaimer
Verify dimensions, square footage, and description against product images before purchase. Currently, most attributes were extracted with AI and have not been manually reviewed.
My Home Floor Plans, Inc. does not assume liability for any deviations in the plans. All information must be confirmed by your contractor prior to construction. Dimensions govern over scale.
