Versatile house and Garage Plan with Storage and Workshop
Discover a detailed CAD blueprint for a versatile house and garage plan featuring 3 bays, storage, a full bathroom, vaulted ceiling, and covered porch designs.
Original price was: $1,582.56.$896.79Current price is: $896.79.
999 in stock
| Width | 36'-0" |
|---|---|
| Depth | 29'-8" |
| Unhtd SF | |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| Unhtd SF Range | |
| # Garage Bays | |
| Architectural Styles | |
| Indoor Features | |
| Outdoor Features | |
| Garage Features | |
| Ceiling Features | |
| Structure Type | |
| Exterior Material | |
| # Front Elevations | |
| Depth Range | |
| Width Range | |
| After Build Photos |
Versatile Garage with Living Space and Storage – CAD Plan
Discover this 3-bay garage and workshop floor plan with full bathroom, vaulted ceiling, and storage—includes CAD blueprints and covered porch designs.
This garage workshop plan offers a perfect mix of function and flexibility. Designed for multipurpose living, it’s ideal for vehicle storage, tools, and even comfortable short stays.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: Includes a finished full bathroom for added convenience.
- Unheated extras: Spacious 3-car garage bays and a large storage room ideal for seasonal gear or equipment.
Bedrooms & Bathrooms
- No dedicated bedroom—but the floor plan is designed to support temporary or flexible living arrangements.
- Includes 1 full bathroom, ideal for workshop use or transitional space.
Interior Highlights
- Vaulted ceilings in the main area provide a sense of openness.
- Functional floor layout makes it perfect for hobbyists, DIYers, or small business storage. See more functional plans.
- Concrete monolithic slab foundation ensures long-term durability.
- Ample storage space keeps your tools, outdoor gear, or inventory neatly organized.
Outdoor Living Features
- Covered front porch offers protection from the elements and a welcoming aesthetic.
- Brick and siding exterior for classic curb appeal and longevity.
Architectural Style: Garage Workshop
This design blends versatile utility with a clean, classic exterior—perfect for families, hobbyists, or professionals needing a mix of form and function.
Included Benefits with Every Plan
- CAD + PDF Files: Easily editable, printable, and ready to build.
- Unlimited Build License: Build once—or 100 times—with no extra fees.
- Free Foundation Changes: Swap between slab, crawlspace, or basement.
- Structural Engineering Included: Code-compliant and professionally stamped.
- Lower Modification Costs: Up to 50% less than competitors.
- View Before You Buy: See every sheet in advance.
