15-1864 GARAGE

Original price was: $399.00.Current price is: $298.00.

999 in stock

Product total
Options total
Grand total
Width

22'-0"

Depth

27'-2"

Unhtd SF

Bedrooms

Bathrooms

# of Floors

Unhtd SF Range

# Garage Bays

Architectural Styles

Garage Features

,

Ceiling Features

Structure Type

Exterior Material

# Front Elevations

Depth Range

Width Range

After Build Photos

Custom Garage Floor Plan | CAD house Design & Architectural Blueprints

Discover this custom garage floor plan with detailed CAD architectural designs, featuring 2 bays, 9ft ceilings, and durable siding exterior. Perfect for any house!

A Perfect Detached Garage Floor Plan for Every house
If you’re in search of a well-designed detached garage with clear, professional plans, this structure is ideal for you! Featuring a 2-car garage, this blueprint is a practical solution for homeowners, architects, or builders wanting additional storage space or parking without sacrificing aesthetic appeal. The included CAD architectural designs ensure every detail is accounted for.
Spacious Yet Compact: A Practical Design
Measuring 22 feet wide and 27 feet deep, this garage provides over 623 square feet of unheated space. The generous 9ft ceilings make it versatile for accommodating larger vehicles or extra storage. With its front entry layout and tidy siding exterior, this garage is both functional and visually appealing.
Architectural Features and Benefits
* Structure Type: Detached, standalone construction for added flexibility.
* Garage Bays: Room for two vehicles, offering sufficient convenience.
* Ceiling Height: High ceilings (9 ft+) create ample vertical space.
* Materials: Durable siding ensures longevity and a classic look.
* Foundations: Stable slab foundation to maintain structural integrity.
Easy to Customize with a Traditional Aesthetic
This garage’s traditional design style makes it an excellent addition to a variety of houses. The simple, rectangular layout makes it easy to attach to an existing driveway or include in new builds with minimal effort. The accompanying architectural plan and detailed CAD blueprints simplify construction, leaving little room for error.
Ideal for Homeowners and Professionals
Whether you’re a homeowner seeking added parking or a professional looking to create functional secondary spaces, this design offers unmatched adaptability. The flexibility of the CAD files included allows you to make modifications if your requirements change.
Benefits Included with Every Plan
Along with this plan, you’ll receive the PDF and CAD files, an unlimited-build license, and free foundation changes. Structural engineering is included with every purchase, and modification services are more affordable compared to competitors. Ready to create your ideal garage? Reach out to support@https://myhomefloorplans.com today!
