Detached Garage house Blueprint with Workshop Design

Explore this functional detached garage house plan with a spacious floor blueprint perfect for a workshop. Complete with CAD files and modification options!

16-1237 BOAT GARAGE

Original price was: $574.56.Current price is: $325.59.

999 in stock

Product total
Options total
Grand total

Width

34'-0"

Depth

34'-0"

Unhtd SF

Bedrooms

Bathrooms

# of Floors

Unhtd SF Range

# Garage Bays

Indoor Features

Outdoor Features

Garage Features

, ,

Structure Type

Exterior Material

# Front Elevations

Depth Range

Width Range

After Build Photos

Detached Garage House Plan with Workshop and Brick Exterior

Explore this 1, 156 sq. ft. detached garage house plan with spacious bays, workshop layout, and timeless brick architecture—includes editable CAD files and engineering.

This detached garage house plan offers a perfect mix of utility and architectural charm. Designed for versatility, it combines workshop-ready space with classic curb appeal for any property type.

Key Features of the Home Plan

Living Areas – Heated & Unheated

  • Heated area: None – this structure is a dedicated unheated garage and workshop.
  • Unheated extras: 1, 156 sq. ft. of garage and workshop space, including oversized bays and porch coverage.

Bedrooms & Bathrooms

  • No bedrooms or bathrooms—this is a dedicated garage and workspace structure.
  • Perfect as a companion to your primary residence or ADU.

Interior Highlights

  • Open workshop layout ideal for woodworking, auto repair, or hobbies.
  • Oversized garage bays fit larger vehicles, trailers, or tools.
  • Reinforced framing supports heavy-duty storage and durability.
  • Slab foundation ensures a solid base and easy construction.

Garage & Storage Details

  • Garage Bays: 2 oversized bays with extra width for tool storage or workbenches.
  • Garage Type: Detached front-entry design—ideal for secondary structures or rural properties.
  • Storage: Ample space within bays for tool racks, loft shelving, or hobby stations.

Outdoor Living Features

  • Charming brick exterior adds timeless curb appeal and low-maintenance durability.
  • Covered front porch provides shaded entry and protection from the elements.

Architectural Style: Traditional Detached Garage

This design blends brick construction with a clean, functional layout—perfect for homeowners who value durability and flexible use. Learn more about the Garage & Vehicle Storage Collection or explore practical design inspiration on ArchDaily.

Bonus Features

  • Workshop-ready layout: Includes wall space for shelves, tools, and more.
  • Slab foundation: Durable, simple to build, and perfect for machinery.
  • Brick façade: Enhances appearance and long-term value.

Included Benefits with Every Plan

  • CAD + PDF Files: Easily editable and print-ready for your builder or engineer.
  • Unlimited Build License: Construct the structure as many times as you wish—ideal for property developers.
  • Free Foundation Changes: Adjust between slab, crawlspace, or other configurations as needed.
  • Structural Engineering Included: Every plan includes code-compliant, professionally stamped engineering.
  • Lower Modification Costs: Our in-house team offers changes at up to 50% less than competitors.
  • View Before You Buy: Preview all sheets before purchase—no surprises.

Similar Collections You Might Love

Frequently Asked Questions

What’s included with this garage plan? Every purchase comes with editable CAD files, print-ready PDFs, unlimited build rights, and engineering support.
Can I convert part of the garage into a guest suite? Yes, many customers adapt this plan to add a studio, office, or small apartment with our modification service.
Is this garage suitable for rural or sloped lots? Yes. With its simple slab foundation and detached design, it works well in both flat and varied terrain.
Can I see the full blueprint before buying? Absolutely. Preview all sheets online to ensure the plan meets your needs.
What type of vehicles fit in this garage? Most full-sized trucks, SUVs, golf carts, and even small RVs will fit comfortably in the oversized bays.

Start Building Your Dream Garage Today

Have questions or want to customize this detached garage layout? Email us at [email protected] or use our contact form to get started.

Your ideal garage begins with a detailed plan—customize it and start building with confidence!

What's Included
What's NOT Included
Modifications
Plan Pricing
