20-1922 GARAGE – Custom Garage and Cart CAD Blueprint – 3-Bay Architectural Design
This house blueprint provides a 3-bay garage floor plan with CAD designs, a sleek traditional architectural style, and all the detailed specifications you need.
Original price was: $1,150.56.$651.99Current price is: $651.99.
999 in stock
| Width | 23'-4" |
|---|---|
| Depth | 13'-8" |
| Unhtd SF | |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| Htd SF Range | |
| Unhtd SF Range | |
| # Garage Bays | |
| Architectural Styles | |
| Outdoor Features | |
| Garage Features | |
| Ceiling Features | |
| Structure Type | |
| Exterior Material | |
| # Front Elevations | |
| Depth Range | |
| Width Range | |
| After Build Photos |
Lauren Perez – November 6, 2023
Pure plug-and-play for builders!
Save to Pinterest!
3-Bay Cart Garage Plan with CAD Blueprints & Traditional Design
Explore this functional cart garage plan featuring 3 bays, monolithic slab foundation, 9′ ceilings, and timeless architecture—includes CAD blueprints and full build rights.
This detached garage plan offers the perfect blend of simplicity and versatility. Whether for golf carts, small vehicles, or multipurpose storage, this compact design maximizes space while maintaining a polished aesthetic.
Key Features of the Garage Plan
Living Areas – Heated & Unheated
- Heated area: None—designed specifically as an unheated garage structure.
- Unheated extras: 319 sq. ft. across 3 garage bays plus an open deck area.
Bedrooms & Bathrooms
- This plan does not include bedrooms or bathrooms—ideal for standalone storage or garage needs.
Interior Highlights
- 9-foot ceilings enhance the interior height for easier vehicle access and equipment storage.
- Efficient layout supports carts, ATVs, or lawn equipment with ease.
- Open deck feature extends usable space outdoors—ideal for maintenance or relaxation.
Garage & Storage Details
- Garage Bays: 3 dedicated bays sized for golf carts or compact vehicles.
- Garage Type: Detached garage structure for flexible placement on your property.
- Storage: Ample room for carts, tools, or recreational gear within a streamlined footprint.
Outdoor Living Features
- Uncovered outdoor deck adds versatility and workspace functionality.
- Timeless siding and shingles create a classic look that blends with any home design.
Architectural Style: Traditional Garage
This design features a traditional architectural profile with practical layout elements—perfect for homeowners or builders who appreciate functional form. Learn more about Traditional house plans or explore the influence of classic garage design on Family Handyman.
Bonus Features
- Simple footprint makes it easy to permit and build on smaller or irregular lots.
- Use as a workshop, cart bay, or garden storage—adaptable to your needs.
- Pairs well with other home plans as an accessory structure.
Included Benefits with Every Plan
- CAD + PDF Files: Fully editable and printable—perfect for quick starts or custom builds.
- Unlimited Build License: Construct this plan as many times as needed, with no extra fees.
- Free Foundation Changes: Customize for slab, crawlspace, or basement—at no added cost.
- Structural Engineering Included: Each plan meets code with professional compliance.
- Lower Modification Costs: Save up to 50% versus competitors for custom changes.
- View Before You Buy: Preview every sheet instantly.
Similar Collections You Might Love
- Garage & Vehicle Storage Plans
- Golf Cart Garage Plans
- Detached Garage Plans
- Garage Workshop Plans
- Side Load Garage House Plans
Frequently Asked Questions
Is this garage plan suitable for golf carts? Yes. It’s specifically designed for golf carts or small recreational vehicles across 3 bays.
Can I add insulation and finish the interior? Absolutely. While unheated by default, the structure can be insulated and finished during construction.
Can I view the full blueprint before purchasing? Yes—you can view every sheet before buying.
Are changes allowed to the layout? Of course! We offer fast and affordable customization services—request a quote.
Can this be built on a sloped lot? With a free foundation change, yes! Just let us know your site needs during purchase.
Start Building Your Dream Garage Today
Have questions or ready to customize your plan? Contact our expert team at [email protected] or reach out here.
This 3-bay cart garage plan gives you the function and flexibility you need—let’s bring your vision to life.
