24x30 Garage Floor Plan with Attic and CAD Blueprint Designs

Discover this 24x30 garage house plan featuring detailed CAD blueprints, attic storage, and a front entry design. Perfect for narrow lots and workshop spaces.

8-1741 Garage

Original price was: $1,150.56.Current price is: $651.99.

999 in stock

Product total
Options total
Grand total
Width

24'-0"

Depth

30'-0"

Unhtd SF

Bedrooms

Bathrooms

# of Floors

Unhtd SF Range

# Garage Bays

Indoor Features

Garage Features

Structure Type

Exterior Material

# Front Elevations

Depth Range

Width Range

After Build Photos

24×30 Garage Floor Plan with Attic and CAD Blueprint Designs

Discover this 24×30 garage house plan featuring detailed CAD blueprints, attic storage, and a front entry design—perfect for narrow lots and workshop functionality.

This garage and vehicle storage floor plan offers a compact yet versatile layout. Ideal for homeowners needing extra storage or workshop space, it’s designed to deliver practical use and architectural style.

Key Features of the Garage Plan

Living Areas – Heated & Unheated

  • Heated area: 420 sq. ft. of unfinished space across 1.5 stories.
  • Unheated extras: Includes 120 sq. ft. for attic or storage use.

Garage & Storage Details

  • Garage Bays: Fits 2 vehicles with a front-entry configuration.
  • Garage Type: Detached structure, great for standalone builds.
  • Storage: Includes attic space for tools, equipment, or seasonal décor.

Interior Highlights

  • Open interior layout that allows for workspace customization.
  • Loft attic area provides valuable vertical storage potential.
  • 1.5-story height enables better ventilation and usability.

Outdoor Living Features

  • Front-entry access with wide garage door for vehicle maneuverability.
  • Durable siding exterior for long-lasting curb appeal.

Architectural Style: Traditional Garage Design

This design emphasizes function-first architecture while maintaining a clean and classic exterior. Its compact footprint makes it ideal for narrow lots or as an add-on to an existing residence. Learn more about detached garage styles or read about the value of utility design on Architect Magazine.

Bonus Features

  • Attic storage space with easy ladder or stair access.
  • Ideal for garage workshop setups.
  • Cost-effective build strategy for secondary structures.

Included Benefits with Every Plan

  • CAD + PDF Files: Editable, printable, and ready to build.
  • Unlimited Build License: Construct once or multiple times with no extra fees.
  • Free Foundation Changes: Choose between slab, crawlspace, or basement.
  • Structural Engineering Included: Professionally reviewed and code-compliant.
  • Lower Modification Costs: Save up to 50% compared to other providers.
  • Preview Before You Buy: See every sheet before purchase.
