Ranch Style CAD Floor Plan for Dream house Design and Blueprint
Explore this 1-story ranch floor plan with 3 bedrooms, 2 baths, CAD architecture designs, and custom blueprints. Ideal for small families or starter houses.
Ranch Style CAD Floor Plan for Dream Home Design and Blueprint Explore this efficient 1-story ranch layout with 1,101 heated sq. ft., 3 bedrooms, 2 baths, and detailed CAD blueprints—perfect for small families or starter homes. This Ranch-style house plan offers a perfect mix of comfort and functio…
Read More
Ranch Style CAD Floor Plan for Dream Home Design and Blueprint
Explore this efficient 1-story ranch layout with 1, 101 heated sq. ft., 3 bedrooms, 2 baths, and detailed CAD blueprints—perfect for small families or starter homes.
This Ranch-style house plan offers a perfect mix of comfort and functionality. Designed for practical living, it delivers timeless charm and smart space planning in a compact footprint.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 1, 101 sq. ft. across a single story.
- Unheated extras: Covered front porch and open rear deck.
Bedrooms & Bathrooms
- 3 comfortable bedrooms, including a first-floor Owner Suite with a walk-in closet.
- 2 full bathrooms designed for privacy and convenience.
Interior Highlights
- Open floor plan creates seamless flow between kitchen, dining, and family areas. Explore open layouts.
- 9ft+ ceilings add a sense of spaciousness and light.
- Family room for cozy evenings and quality time.
- Breakfast nook perfect for casual dining and morning routines.
- First-floor laundry room for everyday convenience.
Garage & Storage Details
- Garage Bays: Optional add-on or external garage configurations available.
- Garage Type: Not included by default; compatible with detached garage additions.
- Storage: Functional closets throughout plus walk-in Owner storage.
Outdoor Living Features
- Covered front porch provides welcoming curb appeal.
- Open rear deck ideal for grilling or lounging outdoors.
- Brick and shake siding for traditional charm and durability.
Architectural Style: Ranch
This compact Ranch-style blueprint uses classic proportions and smart CAD planning to make every square foot count. Learn more about the ranch design style or discover its history on ArchDaily.
Bonus Features
- Flexible layout for future additions or upgrades
- Affordable construction with efficient heating/cooling zones
- Starter-friendly design with quality architectural detailing
Included Benefits with Every Plan
- CAD + PDF Files: Fully editable and ready to print or build.
- Unlimited Build License: No limits—build as many times as you wish.
- Free Foundation Changes: Easily switch between crawlspace, slab, or basement.
- Structural Engineering Included: Professionally stamped for building compliance.
- Lower Modification Costs: Save up to 50% compared to other providers.
- View Before You Buy: Preview the full blueprint set.
Similar Collections You Might Love
- Small House Plans
- Traditional House Plans
- Covered Porch House Plans
- Kitchen Island Plans
- Narrow Lot House Plans
Frequently Asked Questions
What’s included with this ranch-style CAD floor plan? You’ll receive editable CAD files, printable PDFs, unlimited build rights, structural engineering, and free foundation changes.
Can I modify this house layout? Yes—our team offers fast, affordable changes. Start customizing here.
Is this a good plan for first-time buyers? Absolutely. It’s cost-efficient, compact, and designed for practical living.
Does it include a garage? The base plan does not include a garage, but it supports various optional garage add-ons.
Can I see the full blueprint set before purchasing? Yes! Preview every sheet before you buy.
Start Building Your Dream Home Today
Have questions or want to personalize this plan? Contact our team at [email protected] or submit your request here.
Build with confidence—your dream house starts with the right floor plan!
Original price was: $1,150.56.$651.99Current price is: $651.99.
999 in stock
| Width | 56'-0" |
|---|---|
| Depth | 30'-0" |
