Cozy Cabana House Plan – Vaulted Ceiling, Outdoor Fireplace & CAD Blueprints
This compact 20′ x 20′ cabana house plan features a vaulted ceiling, covered porch, and outdoor fireplace—includes full CAD designs and unlimited build license.
This cozy cabana-style house plan offers the perfect mix of relaxation and functionality. Designed for outdoor living, it’s ideal as a backyard retreat, poolside lounge, or guest pavilion—combining timeless charm with thoughtful architectural details.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: Approx. 400 sq. ft. within a 20′ x 20′ footprint—efficient and purposeful.
- Unheated extras: Covered porch and fireplace area ideal for outdoor gatherings.
Bedrooms & Bathrooms
- While not a full residential layout, this cabana design easily accommodates a seating area, wet bar, and powder room depending on your needs.
- Its open layout offers versatility for guest use, relaxation, or entertaining.
Interior Highlights
- Vaulted ceilings create vertical space, making the interior feel spacious and open.
- Simple, open layout ensures maximum flexibility for furniture or built-in installations.
- Outdoor fireplace enhances ambiance and usability through multiple seasons. See more plans with outdoor fireplaces.
Garage & Storage Details
- Garage Bays: None included—but can be paired with detached garage plans.
- Storage: Optional cabinetry or attic access possible in roof truss system.
Outdoor Living Features
- Covered porch offers shaded comfort and all-weather usability.
- Outdoor fireplace turns this structure into a year-round retreat.
- Rustic exterior materials—stone, wood, and natural finishes—create organic curb appeal.
Architectural Style: Cabana / Outdoor Living Pavilion
This structure is designed to complement backyard landscaping and poolside aesthetics. Whether used as a covered deck addition or a free-standing guest structure, it delivers serenity and function in one elegant package. Learn about modern pavilion design trends for inspiration.
Bonus Features
- Pier foundation: Simplifies installation and adapts to various terrain.
- Outdoor lounge concept: Perfect for pool houses or guest seating areas.
- Expandable design: Can be easily modified with a bathroom, kitchenette, or changing room.
Included Benefits with Every Plan
- CAD + PDF Files: Provided for editing, printing, and easy build execution.
- Unlimited Build License: Use this design as many times as needed—perfect for developers or repeat builds.
- Free Foundation Changes: Customize your support system—slab, crawlspace, or pier options available.
- Structural Engineering Included: Fully compliant and engineered to meet code.
- Lower Modification Costs: Save up to 50% compared to other house plan websites.
- View Before You Buy: See all blueprint sheets in advance.
Similar Collections You Might Love
- Cabin House Plans
- Plans with Covered Back Porches
- House Plans with Outdoor Kitchens
- Open Floor Plan Designs
- Small House Plans
Frequently Asked Questions
What’s included with this cabana house plan? You’ll receive CAD files, printable PDFs, engineering documentation, and an unlimited build license—all included.
Can this be used as a guest house? Absolutely. Many customers add a bathroom or kitchenette for full guest suite functionality.
What’s the square footage? This plan covers about 400 sq. ft. (20′ x 20′), ideal for compact properties or backyard retreats.
Is this design customizable? Yes! You can modify it with extra storage, built-ins, or utility features. Request a quote here.
Can I preview the full blueprints? Yes. Preview every included sheet before you buy.
Start Building Your Outdoor Retreat Today
Ready to turn your backyard into a private sanctuary? Reach out to our expert team at [email protected] or send us a message to discuss options and customization.
Whether it’s a peaceful lounge or a stylish pool house—your perfect cabana begins with the right plan.
Original price was: $1,150.56.$651.99Current price is: $651.99.
999 in stock
