Compact house Design with Garage & Loft Living Space Blueprint
Discover our house design combining garage and loft living space in this floor plan! View blueprints with CAD for stylish, small architectural designs today.
Original price was: $1,150.56.$651.99Current price is: $651.99.
999 in stock
| Width | 24'-0" |
|---|---|
| Depth | 26'-1" |
| Htd SF | |
| Unhtd SF | |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| Htd SF Range | |
| Unhtd SF Range | |
| # Garage Bays | |
| Architectural Styles | |
| Indoor Features | |
| Outdoor Features | |
| Bed and Bath Features | Bedrooms on Second Floor, Owner's Suite on Second Floor, Walk-in Closet |
| Kitchen Features | |
| Garage Features | |
| Ceiling Features | |
| Structure Type | |
| Exterior Material | |
| # Front Elevations | |
| Depth Range | |
| Width Range | |
| After Build Photos |
Compact Home Design with Garage & Loft Living Space Blueprint
Discover this small-space house plan with 465 heated sq. ft., open loft layout, and garage below—includes CAD files, blueprint, and structural engineering.
This compact garage loft house plan offers a brilliant fusion of efficiency and charm. Whether you’re looking for a guest suite, rental unit, or small starter house, this plan delivers smart living with a stylish footprint.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 465 sq. ft. on the loft level, offering a cozy and functional layout.
- Unheated extras: Large 2-car garage beneath with space for a workshop or storage.
Bedrooms & Bathrooms
- 1 loft-style bedroom with vaulted ceilings and walk-in closet.
- 1 full bathroom smartly integrated into the upper level design.
Interior Highlights
- Vaulted ceilings provide spacious vertical volume and natural light.
- Open floor plan combines living, dining, and kitchenette into one stylish space. See more open concept plans.
- Kitchenette with eating bar enhances utility and comfort.
- Loft space can serve as a bedroom, home office, or creative studio.
Garage & Storage Details
- Garage Bays: 2-car garage with front entry access.
- Garage Type: Attached and located below the main living area.
- Storage: Includes dedicated storage area and workshop potential within garage.
Outdoor Living Features
- Covered front porch—perfect for relaxing outdoors or adding curb appeal.
- Optional balcony extends off the loft, creating private outdoor space.
- Exterior design includes brick, shingle, and siding—classic charm with low maintenance.
Architectural Style: Garage Loft with Traditional Touches
This efficient layout combines modern loft living with traditional exterior finishes. Ideal for downsizers, guest homes, or flexible ADUs. Discover more about our garage apartment house plans or learn about the influence of compact architecture on ArchDaily.
Bonus Features
- Loft can double as a guest suite or short-term rental unit.
- Garage can support storage, workshop use, or conversion.
- Flexible enough for urban infill, ADU setups, or tiny house fans.
Included Benefits with Every Plan
- CAD + PDF Files: Fully editable and print-ready for any builder or contractor.
- Unlimited Build License: Construct multiple units without paying again.
- Free Foundation Changes: Swap from slab to crawlspace or basement at no extra charge.
- Structural Engineering Included: Professionally stamped and code-compliant.
- Lower Modification Costs: Customize affordably—half the price of competitors.
- View Before You Buy: See every plan sheet in advance.
