Modern 2-Story House Plan with Open Floor Layout and CAD Blueprint
Explore this spacious 3, 627 sq. ft. home plan with 4 bedrooms, open-concept design, and CAD blueprints—includes dual garages, covered porches, and vaulted ceilings.
This modern house plan offers a perfect mix of comfort and functionality. Designed for today’s lifestyle, it delivers timeless appeal and smart space planning with all the features builders and homeowners love.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 3, 627 sq. ft. across two thoughtfully designed stories.
- Unheated extras: 1, 588 sq. ft. including dual garages, screened porch, and covered front porch.
Bedrooms & Bathrooms
- 4 spacious bedrooms including a luxurious first-floor Owner Suite with large walk-in closet.
- 4.5 bathrooms designed for privacy and flow—perfect for growing families or entertaining guests.
Interior Highlights
- Vaulted ceilings and 9’+ heights throughout enhance the spacious feel.
- Open floor plan connects the great room, kitchen, and breakfast nook. See open layouts.
- Kitchen island and walk-in pantry make meal prep and storage easy.
- Fireplace adds ambiance and warmth to the central living space. Explore fireplace plans.
- Study and Mudroom: Keep work and daily life organized.
- Recreation Room: Additional space upstairs for entertainment or relaxation.
Garage & Storage Details
- Garage Bays: Dual garages—one 2-car and one 1-car bay.
- Garage Type: Attached front-facing garages for easy access.
- Storage: Ample space in mudroom, laundry, and closets throughout the home.
Outdoor Living Features
- Covered front porch and screened rear porch for relaxing outdoor spaces.
- Backyard patio offers extra room for grilling, dining, and entertaining.
- Beautiful exterior mix of brick, board & batten, and shake siding creates standout curb appeal.
Architectural Style: Transitional Modern
This layout blends classic textures with modern comforts—perfect for families who want a sleek, open layout without sacrificing character. Learn more about modern architecture or explore its history on ArchDaily.
Bonus Features
- Flexible study space ideal for remote work or homeschooling.
- Upstairs recreation room doubles as a game room, media center, or teen hangout.
- Screened-in porch offers comfortable outdoor living year-round.
Included Benefits with Every Plan
- CAD + PDF Files: Fully editable and printable for builders and designers.
- Unlimited Build License: Construct once or many times—no extra cost.
- Free Foundation Changes: Choose from crawlspace, basement, or slab. Learn more here.
- Structural Engineering Included: Every plan meets modern code requirements.
- Lower Modification Costs: Custom changes cost up to 50% less than competitors. Get started.
- View Before You Buy: Preview all blueprint sheets online.
Similar Collections You Might Love
- 4 Bedroom House Plans
- House Plans with Owner Suite on Main
- Kitchen Island Floor Plans
- Covered Porch Home Designs
- Plans with Recreation Rooms
Frequently Asked Questions
Are both garages included in the square footage? No, the 1, 588 sq. ft. of unheated space includes the garages, porch, and patio separately.
Can I modify the number of bedrooms? Yes! Our CAD files are fully editable and we offer professional modification services.
Is there a version with a slab foundation? Absolutely. Foundation options include slab, crawlspace, and basement at no additional cost.
Are these plans engineered for my state? All plans include structural engineering. Additional local code compliance may be needed depending on your region.
Can I build this house more than once? Yes. Our unlimited-build license gives you full rights to reuse the design.
Start Building Your Dream Home Today
Have questions or want help customizing this plan? Reach out to our friendly team at [email protected] or contact us here.
Design with confidence—your perfect floor plan is just a few clicks away!
