Modern Apartment Complex Floor Plan with CAD Designs
Explore a sleek modern apartment complex floor plan featuring 1-2 bedrooms, open layouts, and CAD blueprints. Perfect for architects and house designers.
Modern Apartment Complex Floor Plan with 1–2 Bedroom Units and CAD Designs
Explore this multi-story apartment complex plan featuring modern 1–2 bedroom layouts, open-concept living, and CAD blueprints—perfect for urban developers and architects.
This modern apartment complex design offers a perfect blend of style and functionality. Designed with urban density and resident comfort in mind, this plan provides efficient layouts with elevated amenities across three spacious stories.
Key Features of the Apartment Complex Plan
Living Areas – Heated & Unheated
- Heated area: Approximately 10, 000+ sq. ft. total across three stories (individual unit square footage varies by layout).
- Unheated extras: Covered patios, balconies, exterior stairwells, and communal deck space.
Bedrooms & Bathrooms
- Mix of 1-bedroom and 2-bedroom units, ideal for singles, couples, and small families.
- Each unit includes 1–2 bathrooms, depending on size, with private access and optional guest bath.
Interior Highlights
- Open floor plans ensure seamless flow between living, dining, and kitchen areas. See open layout designs.
- 9’+ ceilings throughout all units enhance light and airiness.
- Kitchen islands and breakfast bars maximize counter space and functionality.
- Walk-in closets in most bedrooms offer generous storage.
- Laundry area in every unit for private convenience.
Garage & Storage Details
- Parking: On-site ground-level or adjacent lot parking, optional garage bays available.
- Bike storage: Optional bike rack area for eco-conscious residents.
- Shared storage: Hall closets and basement utility rooms in common areas.
Outdoor Living Features
- Private balconies, patios, or covered decks in most units.
- Stucco exterior for sleek, modern curb appeal.
- Optional community courtyard or rooftop deck for resident enjoyment.
Architectural Style: Modern Urban Multi-Family
This design reflects contemporary urban aesthetics with efficient layouts and clean lines. Ideal for city developers and architects prioritizing sustainability, rental yield, and modern lifestyle trends. Learn more about modern house plans or explore the principles of modern multi-family housing.
Bonus Features
- Slab foundation for cost-efficient construction in urban settings.
- Energy-efficient layout promotes lower operating costs.
- CAD files included for easy adaptation or expansion by your architect.
Included Benefits with Every Plan
- CAD + PDF Files: Easily editable, printable, and ready to build.
- Unlimited Build License: Develop multiple buildings with no extra fees.
- Free Foundation Changes: Adapt the design to your lot—slab, crawlspace, or basement included.
- Structural Engineering Included: Professionally stamped and code-compliant.
- Lower Modification Costs: Customize floor plans for 50% less than competitors.
- View Before You Buy: Preview every sheet and elevation.
Similar Collections You Might Love
- Duplex House Plans
- Townhome Floor Plans
- Triplex House Plans
- Garage Apartment Plans
- Plans with Open Floor Layouts
Frequently Asked Questions
How many apartment units are included? This plan can accommodate up to 6–12 units depending on configuration—customizable per your needs.
Is this plan scalable for larger developments? Yes! The CAD files allow your architect or builder to scale vertically or horizontally with ease.
Can this be used for mixed-use development? Definitely. Ground-floor retail or commercial options can be added with foundation changes.
Are the blueprints ready for permit submission? Yes, they include structural engineering, making the permitting process smoother.
Can I preview all design sheets? Absolutely. Click here to view all sheets before purchasing.
Start Building Your Apartment Project Today
Want to scale your development project with a modern, stylish apartment complex? Email our team or contact us online to begin customization or bulk licensing.
Build smarter. Customize faster. And launch your multi-family project with complete confidence today!
