Elegant 3-Story House Plan with 5 Bedrooms and CAD Blueprints
Discover this stunning 3-floor architectural design featuring 3, 900 heated sq. ft., 5 bedrooms, a flexible garage layout, and CAD blueprints included.
This Traditional Craftsman house plan offers a perfect mix of comfort and functionality. Designed for modern living, it delivers timeless charm and smart space planning.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 3, 900 sq. ft. across three thoughtfully designed levels.
- Unheated extras: Spacious garage bays, attic storage, and screened porch.
Bedrooms & Bathrooms
- 5 spacious bedrooms located on the second floor, including a luxurious Owner Suite with walk-in closet.
- Multiple bathrooms positioned for privacy and convenience across all floors.
Interior Highlights
- Vaulted ceilings throughout enhance the elegance and spaciousness.
- Open floor plan connecting family room, kitchen, and dining areas. View open layouts.
- Kitchen island and cozy breakfast nook for casual dining and entertaining.
- Fireplace in the family room adds warmth and character. Browse fireplace plans.
Garage & Storage Details
- Garage Bays: 3-car garage with both front and side entry options.
- Garage Type: Attached configuration for convenience and security.
- Storage: Generous attic space, mudroom storage, and bonus room closet areas.
Outdoor Living Features
- Covered front porch perfect for relaxing with neighbors and friends.
- Screened porch ideal for enjoying outdoor meals or evening breezes.
- Stone, siding, and shingle finishes add visual appeal and durability.
Architectural Style: Traditional Craftsman
This design blends timeless materials and thoughtful details—perfect for families who value character and efficiency in one package. Learn more about the Traditional Craftsman style or explore its roots on ArchDaily.
Bonus Features
- Dedicated office/study space for remote work or creative projects.
- Recreational room for entertainment or fitness use.
- Bonus room offering flexibility as a hobby room, guest suite, or den.
Included Benefits with Every Plan
- CAD + PDF Files: Easily editable, printable, and ready to build.
- Unlimited Build License: Build once—or 100 times—with no extra fees.
- Free Foundation Changes: Swap between slab, crawlspace, or basement.
- Structural Engineering Included: Code-compliant and professionally stamped.
- Lower Modification Costs: Up to 50% less than competitors.
- View Before You Buy: See every sheet in advance.
Similar Collections You Might Love
- 5-Bedroom House Plans
- House Plans with Bonus Room
- Covered Porch House Plans
- Traditional House Plans
- Plans with Home Office
Frequently Asked Questions
Does this house plan include blueprints and CAD files? Yes, you’ll receive editable CAD files, printable PDFs, and full construction-ready blueprints.
Can I build this house more than once? Absolutely. It includes an unlimited-build license at no extra cost.
What foundation options are available? Slab, crawlspace, and basement—all included with free switching.
Is this plan good for multi-generational living? With 5 bedrooms and flexible spaces like a bonus and recreation room, it’s ideal for extended families.
Where can I view all the plan sheets? Preview every sheet before you buy.
Start Building Your Dream Home Today
Have questions or want to personalize your plan? Contact our expert team at [email protected] or fill out our form.
Your future house starts with a great plan—customize it and build with confidence!
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
Unless shown, the plan will not have the electrical layout. We can provide electrical layouts at $100 for 0-1499 sq. ft. home plans and $200 for 1500+ sq. ft. plans. This includes details such as recessed lights, fan/lights, switches, outlets, cable tv & telephone locations, exterior flood light locations, weather proof outlets, heat/vent/light locations…etc. After you receive the electrical layouts, review and mark any desired changes. Take a picture and we will make any and all modifications at NO EXTRA CHARGE. And do not worry if you need to go back and forth a few times. This is inclusive of the $200 fee. Turnaround time averages 2 days.
