Versatile Modern house Design with Floor Plan and CAD Blueprint
Discover a spacious modern house design featuring 4 bedrooms, 4 baths, and a bonus room. This stunning CAD blueprint offers a layout ideal for narrow lots.
9 FT+ Ceilings | Attics | Bonus Rooms | Covered Front Porch | Covered Rear Porches | Designer Favorite | Eating Bar | Great Room | Home Plans with Mudrooms | Jack and Jill | Kitchen Island | Large | Living Room | Modern Craftsman | Narrow | New American | Office/Study | Open Floor Plan Designs | Owner’s Suite on Second Floor | Second Floor Bedroom | Traditional Farmhouse | Transitional | Upstairs Laundry Room | Vaulted Ceiling | Walk-in Closet | Walk-in Pantry
Original price was: $2,302.56.$1,304.79Current price is: $1,304.79.
999 in stock
| Width | 24'-3" |
|---|---|
| Depth | 65'-0" |
| Htd SF | |
| Unhtd SF | |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| Htd SF Range | |
| Unhtd SF Range | |
| # Garage Bays | |
| Architectural Styles | Modern Craftsman, New American, Traditional Farmhouse, Transitional |
| Indoor Features | Attic, Bonus Room, Great Room, Living Room, Mudroom, Office/Study, Open Floor Plan, Upstairs Laundry Room |
| Outdoor Features | |
| Bed and Bath Features | Bedrooms on Second Floor, Jack and Jill Bathroom, Owner's Suite on Second Floor, Walk-in Closet |
| Kitchen Features | |
| Ceiling Features | |
| Structure Type | |
| Exterior Material | |
| # Front Elevations | |
| Depth Range | |
| Width Range | |
| After Build Photos |
Versatile 3-Story Modern House Plan with CAD Design for Narrow Lots
Discover this flexible modern house plan with 3, 428 heated sq. ft., 4 bedrooms, 4 baths, and CAD blueprints—perfect for narrow lots and urban living.
This modern house plan offers a perfect mix of comfort and functionality. Designed for modern living, it delivers timeless charm and smart space planning.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 3, 428 sq. ft. spread over three thoughtfully designed floors.
- Unheated extras: Covered front porch, rear porch, and potential balcony space.
Bedrooms & Bathrooms
- 4 spacious bedrooms including a luxurious second-floor Owner Suite with walk-in closet.
- 4 full bathrooms offering comfort and privacy on every level.
Interior Highlights
- Vaulted ceilings create a sense of openness and elegance.
- Open floor plan integrates living, kitchen, and dining spaces. View open layouts.
- Kitchen island paired with a walk-in pantry for maximum functionality.
- Bonus room ideal for a recreation space, guest suite, or office.
- Fireplace feature adds warmth and a central focal point. Browse fireplace plans.
Garage & Storage Details
- Garage Bays: 1-car garage suitable for compact lots.
- Garage Type: Front-entry, attached garage for convenience in urban settings.
- Storage: Built-in storage, laundry room on upper level, and bonus closet spaces.
Outdoor Living Features
- Covered front and rear porches for all-season outdoor enjoyment.
- Exterior elements include modern siding and shingles for mixed-texture appeal.
Architectural Style: Transitional / Modern Craftsman
This design blends timeless materials and thoughtful details—perfect for families who value character and efficiency in one package. Learn more about the Transitional style or explore its roots on ArchDaily.
Bonus Features
- Flexible bonus room adaptable as media center or office.
- Jack and Jill bathroom connecting secondary bedrooms for added efficiency.
- Second-floor laundry room enhances daily convenience.
Included Benefits with Every Plan
- CAD + PDF Files: Easily editable, printable, and ready to build.
- Unlimited Build License: Build once—or 100 times—with no extra fees.
- Free Foundation Changes: Swap between slab, crawlspace, or basement.
- Structural Engineering Included: Code-compliant and professionally stamped.
- Lower Modification Costs: Up to 50% less than competitors.
- View Before You Buy: See every sheet in advance.
Similar Collections You Might Love
- Narrow Lot House Plans
- Modern House Plans
- House Plans with Bonus Room
- Vaulted Ceiling House Plans
- Second Floor Laundry Room Plans
Frequently Asked Questions
What’s included with this house plan? You’ll receive editable CAD files, printable PDFs, structural engineering, and the unlimited-build license, all with free foundation options.
Can this house plan work on a narrow lot? Yes, it’s just 24′-3″ wide—ideal for compact or urban lots. Explore more narrow lot designs.
Can I customize the blueprint layout? Absolutely! We offer quick, affordable modifications. Get your custom quote here.
Where is the laundry room located? The laundry room is on the second floor, near the Owner Suite for ease of use.
Are the CAD files professionally engineered? Yes. Every purchase includes structural engineering compliant with U.S. codes.
Start Building Your Dream Home Today
Have questions or want to personalize your plan? Contact our expert team at [email protected] or fill out our form.
Your future house starts with a great plan—customize it and build with confidence!
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
Unless shown, the plan will not have the electrical layout. We can provide electrical layouts at $100 for 0-1499 sq. ft. home plans and $200 for 1500+ sq. ft. plans. This includes details such as recessed lights, fan/lights, switches, outlets, cable tv & telephone locations, exterior flood light locations, weather proof outlets, heat/vent/light locations…etc. After you receive the electrical layouts, review and mark any desired changes. Take a picture and we will make any and all modifications at NO EXTRA CHARGE. And do not worry if you need to go back and forth a few times. This is inclusive of the $200 fee. Turnaround time averages 2 days.
