Craftsman house Floor Plan with CAD Design for 5 Bedrooms
Explore this stunning 5-bedroom Craftsman house plan featuring detailed CAD designs. With an open floor plan and spacious living areas, it's perfect for your dream house.
Affordable | Breakfast Nook | Covered Front Porch | Craftsman | Dining Room | First-Floor Bedrooms | Jack and Jill | Kitchen Island | Living Room | Open Floor Plan Designs | Owner's Suite | Owner’s Suite on the First Floor | Smooth & Conventional | Split Bedroom | Starter Home | Traditional | Uncovered Deck | Walk-in Closet
Original price was: $1,150.56.$651.99Current price is: $651.99.
999 in stock
| Width | 34'-8" |
|---|---|
| Depth | 50'-8" |
| Htd SF | |
| Unhtd SF | |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| Htd SF Range | |
| Unhtd SF Range | |
| # Garage Bays | |
| Architectural Styles | |
| Indoor Features | Dining Room, Kitchen, Living Room, Open Floor Plan, Owner's Suite |
| Outdoor Features | |
| Bed and Bath Features | Bedrooms on First Floor, Jack and Jill Bathroom, Owner's Suite on First Floor, Split Bedrooms, Walk-in Closet |
| Kitchen Features | |
| Ceiling Features | |
| Structure Type | |
| Exterior Material | |
| # Front Elevations | |
| Depth Range | |
| Width Range | |
| After Build Photos |
Craftsman Home Floor Plan with CAD Design for 5 Bedrooms
Explore this stunning 5-bedroom Craftsman house plan with 1, 259 heated sq. ft., open floor layout, and covered outdoor spaces—CAD files and structural engineering included.
This Craftsman-style house plan offers a perfect mix of traditional charm and modern comfort. Thoughtfully designed for families, it maximizes space, light, and functionality in a compact footprint.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 1, 259 sq. ft. on a single level for accessible living.
- Unheated extras: Covered front porch and rear deck for outdoor enjoyment.
Bedrooms & Bathrooms
- 5 comfortable bedrooms including a first-floor Owner Suite with walk-in closet.
- 2 full bathrooms, including a convenient Jack and Jill layout for shared use.
Interior Highlights
- Open floor plan connects the kitchen, living, and dining spaces. See more open layouts.
- Kitchen island offers meal prep space and casual dining.
- Spacious living room designed for family gatherings and entertainment.
- Owner Suite on the first floor promotes privacy and accessibility.
Garage & Storage Details
- Garage Bays: Optional add-on detached or attached garage available.
- Garage Type: Flexible options to suit your lot and preference.
- Storage: Generous closets throughout, including walk-in options.
Outdoor Living Features
- Covered front porch perfect for greeting guests or enjoying your morning coffee.
- Uncovered rear deck ideal for BBQs, lounging, or outdoor entertaining.
- Classic Craftsman materials add curb appeal and timeless style.
Architectural Style: Craftsman
This plan features timeless Craftsman architecture—blending shingle textures, clean lines, and practical layouts. Learn more about the Craftsman style or explore its roots on ArchDaily.
Bonus Features
- Jack and Jill bathroom for privacy and efficiency
- All bedrooms on one level—ideal for families with young children or aging in place
- Compact, functional footprint suitable for narrow or small lots
Included Benefits with Every Plan
- CAD + PDF Files: Instantly printable and editable for seamless build prep.
- Unlimited Build License: Build this house as many times as you like—no extra fees.
- Free Foundation Modifications: Choose slab, crawlspace, or basement at no cost. See how it works.
- Structural Engineering: Professionally stamped and ready for code compliance. Learn about structural plans.
- Lower Modification Costs: We offer changes for less than half the price of competitors. Get a quote here.
- View Before You Buy: Preview every sheet included in the plan set.
Similar Collections You Might Love
- 5-Bedroom House Plans
- Small House Plans
- Plans with First Floor Owner Suites
- Narrow Lot House Plans
- Covered Porch House Plans
Frequently Asked Questions
Does this plan work well for first-time builders? Yes, this design is simple to build and includes full construction-ready documents with CAD files and PDFs.
Are all bedrooms located on the same level? Yes, all five bedrooms are on the first floor, making it ideal for accessibility and family living.
Can this home be built on a narrow lot? Definitely. Its compact width and layout are ideal for smaller or urban lots.
Is this home good for aging in place? Absolutely. With no stairs and wide open access, it’s ideal for multigenerational living or long-term comfort.
Are customization services available? Yes, you can request fast and affordable plan modifications directly from our team. Contact us here.
Start Building Your Dream Home Today
Have questions or want to personalize this design? Email us anytime at [email protected] or fill out our quick form.
Your future house starts with a great plan—customize it, preview it, and build it with confidence!
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
Unless shown, the plan will not have the electrical layout. We can provide electrical layouts at $100 for 0-1499 sq. ft. home plans and $200 for 1500+ sq. ft. plans. This includes details such as recessed lights, fan/lights, switches, outlets, cable tv & telephone locations, exterior flood light locations, weather proof outlets, heat/vent/light locations…etc. After you receive the electrical layouts, review and mark any desired changes. Take a picture and we will make any and all modifications at NO EXTRA CHARGE. And do not worry if you need to go back and forth a few times. This is inclusive of the $200 fee. Turnaround time averages 2 days.
