Craftsman house Plan: Detailed CAD Blueprint and Floor Design
Explore this craftsman house plan with a vaulted ceiling design and 3 bedrooms. Includes CAD blueprints, open-floor layout, and stunning architecture details.
Original price was: $1,582.56.$896.79Current price is: $896.79.
999 in stock
| Width | 60'-3" |
|---|---|
| Depth | 77'-8" |
| Htd SF | |
| Unhtd SF | |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| Htd SF Range | |
| Unhtd SF Range | |
| # Garage Bays | |
| Architectural Styles | |
| Indoor Features | Attic, Downstairs Laundry Room, Family Room, Fireplace, Foyer, Open Floor Plan, Recreational Room, Sunroom |
| Outdoor Features | |
| Bed and Bath Features | Bedrooms on First Floor, Owner's Suite on First Floor, Walk-in Closet |
| Kitchen Features | |
| Garage Features | |
| Ceiling Features | |
| Structure Type | |
| Exterior Material | |
| # Front Elevations | |
| Depth Range | |
| Width Range | |
| After Build Photos |
Craftsman Home Plan: Detailed CAD Blueprint and Floor Design
Explore this craftsman home plan with 3 bedrooms, vaulted ceilings, and an open floor layout—includes CAD blueprints, bonus space, and flexible features.
This Craftsman house plan offers a perfect mix of comfort and functionality. Designed for modern living, it delivers timeless charm and smart space planning.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: Approximately 1.5 stories with a wide 60′-3″ by 77′-8″ footprint, perfect for medium-sized families.
- Unheated extras: Spacious garage, attic, covered porches, and a rear patio for outdoor enjoyment.
Bedrooms & Bathrooms
- 3 comfortable bedrooms, including a luxurious first-floor Owner Suite with a walk-in closet (WIC).
- 2 full bathrooms, conveniently placed to offer privacy for guests and family.
Interior Highlights
- Vaulted ceilings in the family room enhance space and light.
- Open floor plan flows seamlessly between kitchen, dining, and living spaces. View open layouts.
- Kitchen island with seating, perfect for prep or casual dining. Explore kitchen island plans.
- Walk-in pantry and breakfast nook for everyday function and comfort.
- Fireplace anchors the family room for cozy nights. Browse fireplace plans.
Garage & Storage Details
- Garage Bays: 2-car garage with easy front access.
- Garage Type: Attached structure for convenience and efficiency.
- Storage: Attic access, mudroom options, and potential bonus closet space throughout.
Outdoor Living Features
- Covered front and rear porches for relaxing or entertaining in shade.
- Stone and shake exterior finishes showcase classic Craftsman style curb appeal.
- Private rear patio space extends the living area into nature.
Architectural Style: Traditional Craftsman
This design blends timeless materials and thoughtful details—perfect for families who value character and efficiency in one package. Learn more about the Craftsman architectural style or explore its roots on ArchDaily.
Bonus Features
- Upstairs recreational space ideal for hobbies, kids, or home gym use.
- Sunroom option adds natural light and seasonal flexibility.
- Attic storage or possible conversion for future expansion.
Included Benefits with Every Plan
- CAD + PDF Files: Easily editable, printable, and ready to build.
- Unlimited Build License: Build once—or 100 times—with no extra fees.
- Free Foundation Changes: Swap between slab, crawlspace, or basement.
- Structural Engineering Included: Code-compliant and professionally stamped.
- Lower Modification Costs: Up to 50% less than competitors.
- View Before You Buy: See every sheet in advance.
Similar Collections You Might Love
- Traditional House Plans
- Rustic Craftsman House Plans
- Covered Porch House Plans
- House Plans with Attic Storage
- Plans with Main-Level Owner Suites
Frequently Asked Questions
Does this plan include the garage? Yes, the attached 2-car garage is part of the design, with ample access and storage options.
Can I add a bonus room or flex space? Definitely! The upper level is perfect for an optional rec room or home office.
Is this house plan ideal for a family? Absolutely—its 3-bedroom layout and open living areas are designed with family flow in mind.
Can I choose a different foundation? Yes—choose from slab or crawlspace at no extra cost.
How can I preview the floor plan? Preview every sheet before you buy here.
Start Building Your Dream Home Today
Have questions or want to personalize your plan? Contact our expert team at [email protected] or fill out our form.
Your future house starts with a great plan—customize it and build with confidence!
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
Unless shown, the plan will not have the electrical layout. We can provide electrical layouts at $100 for 0-1499 sq. ft. home plans and $200 for 1500+ sq. ft. plans. This includes details such as recessed lights, fan/lights, switches, outlets, cable tv & telephone locations, exterior flood light locations, weather proof outlets, heat/vent/light locations…etc. After you receive the electrical layouts, review and mark any desired changes. Take a picture and we will make any and all modifications at NO EXTRA CHARGE. And do not worry if you need to go back and forth a few times. This is inclusive of the $200 fee. Turnaround time averages 2 days.
