Crafted 2-Story House Plan with CAD Designs & Open Floor Concept
Explore this elegant 2, 891 sq. ft. 2-story house plan featuring 4 bedrooms, 3 baths, and beautifully detailed CAD blueprints—ideal for narrow lots and modern families.
This traditional-style house plan offers a perfect mix of classic charm and modern comfort. Designed with everyday functionality in mind, the architecture showcases an open floor plan, high ceilings, and versatile spaces throughout.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 2, 891 sq. ft. across two thoughtfully designed floors.
- Unheated extras: 1, 338 sq. ft. including a covered front porch, screened rear porch, and spacious 2-car garage.
Bedrooms & Bathrooms
- 4 total bedrooms including a spacious Owner Suite with luxurious layout options.
- 3 full bathrooms ensure convenience and privacy on every level.
Interior Highlights
- Open floor plan promotes seamless living and entertaining. See open layout designs.
- Kitchen with walk-in pantry and breakfast nook designed for everyday efficiency.
- Office/Study space for work-from-home needs or quiet retreat.
- Bonus room and mudroom provide valuable flexibility and organization.
- Ceiling heights of 9ft+ add elegance and visual space.
Garage & Storage Details
- Garage Bays: 2-car capacity.
- Garage Type: Attached with convenient front-entry layout.
- Storage: Thoughtfully integrated mudroom and potential attic options.
Outdoor Living Features
- Charming covered front porch welcomes guests and adds curb appeal.
- Screened rear porch for shaded outdoor enjoyment with added privacy.
Architectural Style: Traditional with Modern Functionality
This design blends timeless materials and smart spatial planning—perfect for families who value character and efficient living. Learn more about the Traditional style or explore its roots on ArchDaily.
Bonus Features
- Flex room serves as a secondary living space, office, or guest suite.
- Recreational area for entertaining, media, or hobbies.
- Narrow-lot friendly footprint with efficient use of space.
Included Benefits with Every Plan
- CAD + PDF Files: Fully editable for customization, plus printable and builder-ready.
- Unlimited Build License: Build your home once—or multiple times—at no extra cost.
- Free Foundation Changes: Switch easily between slab, crawlspace, or basement.
- Structural Engineering Included: Every plan is reviewed and stamped for compliance and safety.
- Lower Modification Costs: Save up to 50% compared to competitor fees.
- View Before You Buy: Preview every sheet before purchasing.
Similar Collections You Might Love
- Narrow Lot House Plans
- Plans with Mudrooms
- Covered Porch House Plans
- Plans with Kitchen Islands
- Plans with Home Offices
Frequently Asked Questions
Does this plan come with both CAD and PDF files? Yes, every purchase includes editable CAD files and print-ready PDFs for your builder or architect.
Can I make layout changes? Absolutely. We offer affordable plan modification services.
Is this house plan ideal for a narrow lot? Yes. Its footprint and garage layout are perfectly suited for urban or tight-lot configurations.
How many stories does this home have? This is a two-story layout with key living spaces on the first floor.
Can I preview the entire plan before buying? Yes! Click here to view all sheets in advance.
Start Building Your Dream Home Today
Questions? Want to personalize this plan? Contact our expert team at [email protected] or send us a message.
Your future house starts with a great plan—customize it and build with confidence!
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
Unless shown, the plan will not have the electrical layout. We can provide electrical layouts at $100 for 0-1499 sq. ft. home plans and $200 for 1500+ sq. ft. plans. This includes details such as recessed lights, fan/lights, switches, outlets, cable tv & telephone locations, exterior flood light locations, weather proof outlets, heat/vent/light locations…etc. After you receive the electrical layouts, review and mark any desired changes. Take a picture and we will make any and all modifications at NO EXTRA CHARGE. And do not worry if you need to go back and forth a few times. This is inclusive of the $200 fee. Turnaround time averages 2 days.
Architectural or Engineering Stamp – handled locally if required
Site Plan
Mechanical Drawings (location of heating and air equipment and duct work) – your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) – your subcontractors handle this
HVAC PLANS are not shown on the blueprints. HVAC system information regarding location of units, what types of units are used, and the duct layout are schematic only and should discuss with your local builder, mechanical (HVAC) contractor, and plumbing contractor. They should be able to provide you with the necessary information based on what your local building codes will allow.
Energy calculations – handled locally when required
Receive a modification estimate within a 24 hours. Our modification team is ready to help you adjust any plan to fit your needs. The modification process is simple and estimates are free!
1. Send photos of markups and email to [email protected]
2. Want to talk to an expert? Call us at 1-800-642-8078
Note: – a sketch of the changes or the website floor plan marked up to reflect changes is a great way to convey the modifications in addition to a written list. You can simply snap a picture and upload/message us HERE.
We are faster, better, and less expensive than our competitors!
When you submit your modification request, a designer will contact you within 24 business hours with a quote.
You can have your plan redesigned in as little as 3- days!
We look forward to hearing from you!
PDF File and CAD File: $ PRICE NOTED NEXT TO ‘ADD TO CART’
PDF File Unlimited Build: $0
Unlimited Build License issued on PDF File Unlimited Build orders.
CAD File: $0
Single Build License issued on CAD File orders.
CAD File Unlimited Build: $0
Unlimited Build License issued on CAD File Unlimited Build orders.
Right Reading Reverse/Mirrored Vertically: $0
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
Mirrored Horizontally: $0
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
Available Foundation Types: See product photos for the foundation type included with the plan. Substituting for a mono slab, stem-wall, or crawl is free of charge.
17-2027 HOME PLAN
WHAT’S INCLUDED IN THE DELIVERY
BOTH a PDF and CAD file are sent to the email provided.
PDF – Can easily be printed at nearby printing store
CAD Files – Delivered as Autocad format. These are NECESSARY for required structrual engineering. Also very helpful for any modifications.
Plans purchased are for “unlimited” or a multi-use license
*Delivered plans are identical to the product images. With most plans, additional details and notes not pictured are also included. If you wish to inquire of these notes/details, please click “Make an Enquiry for this Product” for more information.
