Compact 2-Story Home Plan with Studio & Cart Garage
Explore this compact home design with an upper-level studio, open layout, covered deck, and two-bay cart garage—includes CAD blueprints, unlimited builds, and more.
This narrow lot house plan offers a perfect blend of versatility, functionality, and smart design. With modern architecture and a space-saving layout, it’s ideal for urban dwellers, downsizers, or anyone seeking a sleek and efficient blueprint.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: Approximately 800–1, 000 sq. ft. across two levels.
- Unheated extras: Covered deck, balcony, and a two-cart garage on the lower level.
Bedrooms & Bathrooms
- Upper-level studio that can serve as a flexible living or sleeping space.
- Includes a full bathroom, designed with efficiency and style in mind.
Interior Highlights
- Open floor plan creates a seamless flow between kitchenette, living, and sleeping zones. Browse open floor plans.
- 9ft+ ceilings enhance the visual space and bring in more natural light.
- Compact kitchenette with wet bar—ideal for minimalists or short-term guests.
Garage & Storage Details
- Garage Bays: 2-cart garage suitable for golf carts or compact vehicles.
- Garage Type: Detached, located beneath the studio level.
- Storage: Additional room available in the garage for tools or seasonal items.
Outdoor Living Features
- Covered deck offers protection and comfort for year-round use.
- Private balcony extends the studio living space into the outdoors.
- Perfectly designed for tight lots or infill lots.
Architectural Style: Contemporary Compact
This home design highlights clean lines, modern finishes, and functional layouts. It’s ideal for those seeking minimal maintenance and maximum lifestyle value. Learn more about contemporary house designs or explore compact living inspiration on ArchDaily.
Bonus Features
- Optional flex room design for office, guest suite, or hobby area.
- Dedicated wet bar to maximize kitchenette utility.
- Low maintenance exterior with modern curb appeal.
Included Benefits with Every Plan
- CAD + PDF Files: Fully editable, ready for contractors and modifications.
- Unlimited Build License: Build once or as many times as needed—no added cost.
- Free Foundation Changes: Choose between slab, crawlspace, or basement with no charge. Learn more.
- Structural Engineering Included: All plans are professionally reviewed for safety and compliance.
- Lower Modification Costs: Our fees are up to 50% less than competitors. Request modifications.
- View Before You Buy: Preview full plan sheets online.
Similar Collections You Might Love
- Garage Apartment Plans
- Plans with Covered Decks
- Compact & Narrow Lot House Plans
- Accessory Dwelling Unit (ADU) Plans
- Plans with Balcony Features
Frequently Asked Questions
Is this plan good for narrow lots? Yes! Its small footprint and two-level layout are designed to fit tight or urban spaces.
Does this plan include CAD and PDF files? Absolutely. You’ll receive editable CAD and print-ready PDF files with every purchase.
Can I use this as an ADU? Yes, it’s a great fit for use as an accessory dwelling or guest suite.
Can I see the full plan before I buy? Yes, you can view all plan sheets prior to purchase.
Can I customize this design? Definitely! We offer low-cost modifications to suit your exact needs. Contact us for a quote.
Start Building Your Dream Home Today
Have questions or want to personalize this compact design? Reach out to our team at [email protected] or contact us online.
Smart living starts with a smart design—get your compact dream plan now and build with confidence!
