Custom Entry Gate Pavilion Plan with Courtyard & Brick Detailing
Explore this classic single-story entry gate pavilion with brick materials, slab foundation, covered porch, and CAD-ready blueprints—perfect for estates and private entrances.
This traditional-style pavilion plan offers a perfect blend of elegance and functionality. Designed to elevate curb appeal, this structure is ideal for both residential estates and commercial entrances seeking sophistication and structural integrity.
Key Features of the Pavilion Plan
Living Areas – Heated & Unheated
- Heated area: Less than 1, 500 sq. ft. with a focused use of space.
- Unheated extras: Covered front porch and open-air courtyard features.
Bedrooms & Bathrooms
- Not applicable—this pavilion design serves as a welcoming entry structure or leisure zone.
- Perfect for pairing with adjacent residential or commercial buildings.
Interior Highlights
- Defined foyer space offers a grand sense of arrival.
- Living area included for guest seating or greeting station.
- Open flow design enhances sightlines and entry movement. See open plans.
Garage & Storage Details
- Garage Bays: None included, though entry space can accommodate gate automation or valet parking areas.
- Garage Type: Not applicable.
- Storage: Ample space for seasonal décor or gatehouse utility items.
Outdoor Living Features
- Covered front porch offers shelter and timeless Southern charm.
- Brick exterior with elegant finishes and traditional detailing.
- Includes a courtyard-style layout perfect for gated estates.
Architectural Style: Traditional Southern
This pavilion design showcases classic brickwork, a slab foundation, and covered porch elements that blend perfectly with Southern house plans. Inspired by time-honored estate entryways, this plan brings refinement to any property. Learn more about traditional style design on ArchDaily.
Bonus Features
- Open-air courtyard ideal for landscaping, sculpture display, or decorative lighting.
- Symmetrical layout creates strong architectural presence from both directions.
- Foyer and seating areas perfect for staff or guests awaiting entry.
Included Benefits with Every Plan
- CAD + PDF Files: Fully editable and ready for contractors or architects.
- Unlimited Build License: Use this entry pavilion on multiple projects or properties.
- Free Foundation Changes: Switch between slab, crawlspace, or basement options. Learn more.
- Structural Engineering Included: Professionally engineered for lasting performance and code compliance.
- Lower Modification Costs: Customize for less than half the price of competitors.
- View Before You Buy: Preview every sheet in advance.
Similar Collections You Might Love
- Traditional House Plans
- Courtyard House Plans
- Covered Porch House Plans
- Southern House Designs
- AutoCAD Blocks for Architects
Frequently Asked Questions
Can I use this pavilion plan for a residential entry? Yes! This design works beautifully for estate entrances, driveways, or subdivision gates.
Does this plan come with structural support? Absolutely. All of our plans include structural engineering for peace of mind.
Can I customize the size or materials? Yes. We offer affordable customizations to fit your vision. Request a quote here.
Is this pavilion suitable for commercial use? Definitely. Many clients use this design as part of luxury communities, resorts, or corporate campuses.
Are the CAD files editable? Yes. CAD files allow your builder or architect to make changes easily.
Start Building Your Dream Entry Pavilion Today
Ready to enhance your property with this elegant entry pavilion plan? Reach out to our friendly team at [email protected] or submit your request online.
Bring timeless charm and architectural excellence to your entryway—start your build with confidence today!
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
Unless shown, the plan will not have the electrical layout. We can provide electrical layouts at $100 for 0-1499 sq. ft. home plans and $200 for 1500+ sq. ft. plans. This includes details such as recessed lights, fan/lights, switches, outlets, cable tv & telephone locations, exterior flood light locations, weather proof outlets, heat/vent/light locations…etc. After you receive the electrical layouts, review and mark any desired changes. Take a picture and we will make any and all modifications at NO EXTRA CHARGE. And do not worry if you need to go back and forth a few times. This is inclusive of the $200 fee. Turnaround time averages 2 days.
Architectural or Engineering Stamp – handled locally if required
Site Plan
Mechanical Drawings (location of heating and air equipment and duct work) – your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) – your subcontractors handle this
HVAC PLANS are not shown on the blueprints. HVAC system information regarding location of units, what types of units are used, and the duct layout are schematic only and should discuss with your local builder, mechanical (HVAC) contractor, and plumbing contractor. They should be able to provide you with the necessary information based on what your local building codes will allow.
Energy calculations – handled locally when required
Receive a modification estimate within a 24 hours. Our modification team is ready to help you adjust any plan to fit your needs. The modification process is simple and estimates are free!
1. Send photos of markups and email to [email protected]
2. Want to talk to an expert? Call us at 1-800-642-8078
Note: – a sketch of the changes or the website floor plan marked up to reflect changes is a great way to convey the modifications in addition to a written list. You can simply snap a picture and upload/message us HERE.
We are faster, better, and less expensive than our competitors!
When you submit your modification request, a designer will contact you within 24 business hours with a quote.
You can have your plan redesigned in as little as 3- days!
We look forward to hearing from you!
PDF File and CAD File: $ PRICE NOTED NEXT TO ‘ADD TO CART’
PDF File Unlimited Build: $0
Unlimited Build License issued on PDF File Unlimited Build orders.
CAD File: $0
Single Build License issued on CAD File orders.
CAD File Unlimited Build: $0
Unlimited Build License issued on CAD File Unlimited Build orders.
Right Reading Reverse/Mirrored Vertically: $0
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
Mirrored Horizontally: $0
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
Available Foundation Types: See product photos for the foundation type included with the plan. Substituting for a mono slab, stem-wall, or crawl is free of charge.
20-1974 ENTRY GATE
WHAT’S INCLUDED IN THE DELIVERY
BOTH a PDF and CAD file are sent to the email provided.
PDF – Can easily be printed at nearby printing store
CAD Files – Delivered as Autocad format. These are NECESSARY for required structrual engineering. Also very helpful for any modifications.
Plans purchased are for “unlimited” or a multi-use license
*Delivered plans are identical to the product images. With most plans, additional details and notes not pictured are also included. If you wish to inquire of these notes/details, please click “Make an Enquiry for this Product” for more information.
