Plan 10-1682 – Ache Manor | Colonial Revival – 4-Bed, 3-Bath, 3,306 SF
Colonial Revival and Classical Southern house plan with clapboard siding exterior • 4 bed • 3 bath • 2,800 SF. Wraparound porch, symmetrical façade, open-concept living. Includes CAD+PDF + unlimited build license.
Original price was: $2,476.45.$1,454.99Current price is: $1,454.99.
999 in stock
* Please verify all details with the actual plan, as the plan takes precedence over the information shown below.
| Width | 64'-0" |
|---|---|
| Depth | 53'-0" |
| Htd SF | |
| Unhtd SF | |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| # Garage Bays | |
| Architectural Styles | |
| Indoor Features | Open Floor Plan, Foyer, Mudroom, Great Room, Family Room, Living Room, Fireplace, Office/Study, Recreational Room, Bonus Room, Downstairs Laundry Room, Basement |
| Outdoor Features | |
| Bed and Bath Features | Bedrooms on First Floor, Bedrooms on Second Floor, Owner's Suite on First Floor, Owner's Suite on Second Floor, Walk-in Closet |
| Kitchen Features | |
| Garage Features | |
| Condition | New |
| Ceiling Features | |
| Structure Type | |
| Exterior Material |
No reviews yet.
9 FT+ Ceilings | Affordable | Basement | Basement Garage | Beamed | Bedrooms on First and Second Floors | Bonus Rooms | Breakfast Nook | Colonial Farmhouse | Covered Front Porch | Covered Rear Porches | Craftsman | Designer Favorite | Detached | Downstairs Laundry Room | Family Room | Fireplaces | Fireplaces | First-Floor Bedrooms | Foyer | Front Entry | Great Room | Home Plans with Mudrooms | Kitchen Island | Large House Plans | Living Room | Medium | Narrow Lot Designs | Office/Study Designs | Open Floor Plan Designs | Oversized Designs | Owner’s Suite on Second Floor | Owner’s Suite on the First Floor | Recreational Room | Screened Porches | Second Floor Bedroom | Traditional | Vaulted Ceiling | Walk-in Closet | Walk-in Pantry
Colonial Revival Home Plan with Wraparound Porch and Timeless Southern Charm
Experience classic symmetry, gracious outdoor living, and refined traditional detailing in this 2,800 sq. ft. Colonial Revival home plan with 4 bedrooms and 3 bathrooms—complete with CAD blueprints, structural engineering, and an unlimited build license.
This beautifully balanced Colonial Revival home plan captures the enduring elegance of early American architecture while incorporating modern comfort and functionality. Defined by its symmetrical façade, evenly spaced windows, central entry, and expansive covered porch, this design reflects the architectural heritage that has made Colonial Revival one of the most sought-after traditional home styles in America.
Wrapped in crisp horizontal clapboard siding and framed by a welcoming full-length porch, this two-story residence blends Colonial Revival and Classical Southern influences to create a home that feels stately yet inviting. From its formal curb appeal to its thoughtfully designed interior layout, every detail supports comfortable family living and long-term value.
Home Specifications at a Glance
- Heated Living Area: 2,800 square feet
- Stories: 2
- Bedrooms: 4
- Bathrooms: 3 full baths
- Exterior: Horizontal lap siding (clapboard)
- Porches: Full-width covered front porch + extended outdoor living areas
- Garage: Optional detached or side-entry configuration available
Architectural Style: Colonial Revival with Classical Southern Character
Colonial Revival architecture is defined by order, proportion, and symmetry. This home plan showcases:
- Balanced two-story façade
- Centered front door with classic detailing
- Evenly spaced double-hung windows
- Traditional rooflines with subtle dormer accents
- Full-length covered porch supported by simple columns
The clapboard siding exterior reinforces the historic authenticity of the Colonial Revival style while offering modern durability and low maintenance. The clean white façade paired with dark shutters creates timeless contrast and curb appeal.
For a deeper understanding of Colonial Revival architecture and its American roots, explore this overview from
Fine Homebuilding.
Inviting Outdoor Living: The Wraparound Porch Experience
One of the most compelling features of this Colonial Revival home plan is its expansive covered porch. Unlike many modern suburban homes, this design emphasizes connection with the outdoors.
Key porch features include:
- Full-width front porch ideal for rocking chairs and evening gatherings
- Covered entry for year-round protection
- Architectural columns that reinforce symmetry and structure
- Outdoor entertaining flexibility
The porch not only enhances visual balance but also provides functional outdoor living space—perfect for warm climates and Southern-inspired lifestyles.
Main Level Layout: Classic Structure Meets Modern Flow
Step through the centered front entry and into a thoughtfully organized main floor that respects traditional room placement while embracing open-concept living where it matters most.
Foyer and Formal Spaces
The welcoming foyer establishes symmetry from the moment you enter. Flanking spaces can be configured as:
- Formal dining room
- Home office or study
- Flexible sitting room
These rooms reflect Colonial Revival traditions while remaining adaptable to modern needs.
Open-Concept Living Area
Toward the rear of the home, the layout transitions into a spacious great room and kitchen area designed for everyday living.
Features include:
- Large central kitchen island
- Walk-in pantry
- Open dining area
- Great room with fireplace
- Rear-facing windows for natural light
The open-concept layout encourages connection while preserving defined architectural zones—an ideal balance between historic style and modern practicality.
Kitchen Design: Functionality with Traditional Appeal
The kitchen anchors the home’s daily activity. Designed with efficiency in mind, it offers:
- Generous prep space
- Island seating for casual meals
- Clear sightlines to living areas
- Classic cabinetry layout
- Optional butler’s pantry upgrade
Its placement allows homeowners to entertain seamlessly while maintaining the elegant proportions expected in a Colonial Revival house plan.
Second Floor: Private Retreat Spaces
Upstairs, the 4-bedroom layout ensures comfort for families of all sizes.
Owner’s Suite
The primary suite includes:
- Spacious bedroom layout
- Large walk-in closet
- Private en-suite bathroom
- Dual vanity option
- Separate shower and soaking tub
Positioned for privacy, the owner’s suite maintains the home’s balanced structural layout.
Additional Bedrooms
Three additional bedrooms offer:
- Generous closet space
- Shared hall bath access
- Flexible use as guest room, nursery, or office
The second-floor plan keeps circulation simple and efficient while maintaining symmetry.
Clapboard Siding Exterior: Timeless and Durable
The exterior horizontal lap siding (clapboard) enhances both aesthetic and structural performance.
Benefits include:
- Classic Colonial appearance
- Clean horizontal lines
- Low maintenance materials
- Excellent paint retention
- Moisture-shedding performance
This material choice reinforces authenticity while ensuring longevity.
Energy Efficiency and Build Practicality
Though rooted in historic inspiration, this Colonial Revival home plan incorporates modern building efficiencies:
- Compact two-story footprint reduces foundation cost
- Stacked plumbing walls for cost-effective construction
- Efficient framing layout
- Flexible foundation options (slab, crawlspace, or basement)
These details make the design both beautiful and builder-friendly.
Included With Your Colonial Revival Home Plan
Every purchase includes:
- Editable CAD Files – Modify layout and dimensions easily
- High-Resolution PDF Plan Set – Ready for printing
- Unlimited Build License – Build multiple times with no extra fees
- Structural Engineering Included
- Free Foundation Modifications
This comprehensive package ensures you receive more value and flexibility than traditional plan providers.
Why Choose a Colonial Revival Home Plan?
Homeowners continue to select Colonial Revival a
