Traditional Duplex Home Plan with CAD Designs & Spacious Floor Layout
Explore this stunning two-story traditional duplex house plan with 5, 632 heated sq. ft., vaulted ceilings, bonus rooms, and CAD blueprints—ideal for multi-family living.
This traditional duplex house plan offers a perfect mix of classic architecture and smart space planning. Designed for modern families or builders targeting multi-unit investment properties, it delivers luxury and functionality under one roof.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 5, 632 sq. ft. spread across two full stories.
- Unheated extras: Side-entry 2-car garage, front and rear porches, and storage areas.
Bedrooms & Bathrooms
- 3 well-appointed bedrooms provide plenty of privacy and comfort for each household.
- 3 full bathrooms are conveniently placed to accommodate family or guest needs.
Interior Highlights
- Vaulted ceilings in key living spaces elevate the home’s elegance.
- Open floor plan encourages interaction between kitchen, dining, and great rooms. View open layouts.
- Fireplace feature in the main gathering area creates a cozy ambiance. Browse fireplace plans.
- Bonus room offers versatility—perfect for a home office, gym, or playroom.
Garage & Storage Details
- Garage Bays: 2-car side-entry garage provides easy access and curb appeal.
- Garage Type: Attached with generous storage capacity.
- Storage: Dedicated utility space, closets, and optional attic storage.
Outdoor Living Features
- Covered front porch and spacious rear porch extend your living space outdoors.
- Exterior cladding includes timeless stone and shingle, reinforcing a classic duplex look.
Architectural Style: Traditional Duplex
This design blends classic curb appeal with practical multi-family living—perfect for extended families or dual-occupancy investors. Learn more about the Traditional Style or explore its influence on ArchDaily.
Bonus Features
- Separate great room and living room layouts accommodate formal and casual spaces.
- Flexible bonus room for home office, playroom, or guest suite use.
- Slab foundation included for affordability and faster builds.
Included Benefits with Every Plan
- CAD + PDF Files: Delivered in editable formats for builders and architects.
- Unlimited Build License: No extra charge for multiple constructions.
- Free Foundation Changes: Choose from slab, crawlspace, or basement. Learn more.
- Structural Engineering Included: Professionally stamped, ready for permits.
- Lower Modification Costs: Save up to 50% vs. competitors. Request custom changes.
- View Before You Buy: Access every sheet upfront.
Similar Collections You Might Love
- Duplex House Plans
- Traditional House Plans
- House Plans with Bonus Room
- Side Entry Garage Plans
- Covered Back Porch House Plans
Frequently Asked Questions
What’s included with this house plan? All plans include CAD + PDF files, unlimited build licenses, structural engineering, and free foundation options.
Is this design customizable? Yes! Submit a request to modify anything from layout to elevations. Contact us here.
How many levels are included? This is a 2-story duplex design offering plenty of living space on both levels.
Can I build this for investment purposes? Absolutely. It’s perfect for rental units or family co-living setups.
Do I need to buy twice for each unit? No! One purchase covers both units thanks to our unlimited build license.
Start Building Your Dream Home Today
Have questions or ready to personalize your blueprint? Our team is here to help—email us at [email protected] or fill out the contact form.
Secure your traditional duplex plan today and start building smarter—customize with confidence!
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
Unless shown, the plan will not have the electrical layout. We can provide electrical layouts at $100 for 0-1499 sq. ft. home plans and $200 for 1500+ sq. ft. plans. This includes details such as recessed lights, fan/lights, switches, outlets, cable tv & telephone locations, exterior flood light locations, weather proof outlets, heat/vent/light locations…etc. After you receive the electrical layouts, review and mark any desired changes. Take a picture and we will make any and all modifications at NO EXTRA CHARGE. And do not worry if you need to go back and forth a few times. This is inclusive of the $200 fee. Turnaround time averages 2 days.
Architectural or Engineering Stamp – handled locally if required
Site Plan
Mechanical Drawings (location of heating and air equipment and duct work) – your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) – your subcontractors handle this
HVAC PLANS are not shown on the blueprints. HVAC system information regarding location of units, what types of units are used, and the duct layout are schematic only and should discuss with your local builder, mechanical (HVAC) contractor, and plumbing contractor. They should be able to provide you with the necessary information based on what your local building codes will allow.
Energy calculations – handled locally when required
Receive a modification estimate within a 24 hours. Our modification team is ready to help you adjust any plan to fit your needs. The modification process is simple and estimates are free!
1. Send photos of markups and email to [email protected]
2. Want to talk to an expert? Call us at 1-800-642-8078
Note: – a sketch of the changes or the website floor plan marked up to reflect changes is a great way to convey the modifications in addition to a written list. You can simply snap a picture and upload/message us HERE.
We are faster, better, and less expensive than our competitors!
When you submit your modification request, a designer will contact you within 24 business hours with a quote.
You can have your plan redesigned in as little as 3- days!
We look forward to hearing from you!
PDF File and CAD File: $ PRICE NOTED NEXT TO ‘ADD TO CART’
PDF File Unlimited Build: $0
Unlimited Build License issued on PDF File Unlimited Build orders.
CAD File: $0
Single Build License issued on CAD File orders.
CAD File Unlimited Build: $0
Unlimited Build License issued on CAD File Unlimited Build orders.
Right Reading Reverse/Mirrored Vertically: $0
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
Mirrored Horizontally: $0
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
Available Foundation Types: See product photos for the foundation type included with the plan. Substituting for a mono slab, stem-wall, or crawl is free of charge.
10-1929 MURGESE-MURGESE DUPLEX
WHAT’S INCLUDED IN THE DELIVERY
BOTH a PDF and CAD file are sent to the email provided.
PDF – Can easily be printed at nearby printing store
CAD Files – Delivered as Autocad format. These are NECESSARY for required structrual engineering. Also very helpful for any modifications.
Plans purchased are for “unlimited” or a multi-use license
*Delivered plans are identical to the product images. With most plans, additional details and notes not pictured are also included. If you wish to inquire of these notes/details, please click “Make an Enquiry for this Product” for more information.
