Beautiful CAD Ranch Floor Plan with 1.5 Stories & Bonus Room
Discover this flexible 4-bedroom ranch house plan with 3 baths, a bonus room, screened porch, and CAD blueprints—designed for modern families and efficient building.
This ranch-style house plan offers a perfect mix of comfort and functionality. Designed for modern living, it delivers timeless curb appeal, open layouts, and smart space planning with 1.5 stories of versatile design.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 2, 495 sq. ft. across 1.5 stories.
- Unheated extras: Screened porch, covered front porch, attic storage, and exterior patio area.
Bedrooms & Bathrooms
- 4 spacious bedrooms including a first-floor Owner Suite with dual vanities and a walk-in closet.
- 3 full bathrooms, including a convenient Jack-and-Jill bath shared between two main-floor bedrooms.
Interior Highlights
- Open floor plan combines kitchen, family room, and dining space for seamless daily living. Explore open layouts.
- Bonus room upstairs can serve as a guest suite, office, or recreation area with its own bath.
- 9-ft ceilings enhance light and spaciousness on the main floor.
- Fireplace in the family room for cozy evenings. View fireplace plans.
- Dedicated laundry room on the main floor for convenience.
- Attic offers ample storage space above.
Garage & Storage Details
- Garage Bays: 2-car garage with front entry.
- Garage Type: Attached and seamlessly integrated into the home’s footprint.
- Storage: Attic space, walk-in closets, and built-in cabinetry enhance organization.
Outdoor Living Features
- Screened porch ideal for seasonal comfort and relaxing outdoors.
- Covered front porch for curb appeal and welcoming entry.
- Spacious rear patio for entertaining or enjoying quiet mornings.
Architectural Style: Ranch with Bonus Room
This thoughtful CAD house design blends classic ranch elements with modern updates. The 1.5-story layout and open-concept living make it perfect for families who value flexibility and comfort. Learn more about Ranch House Plans or explore its architectural background on ArchDaily.
Bonus Features
- Jack-and-Jill bath for functional shared living.
- Screened-in porch included for year-round enjoyment.
- Bonus room with full bath for extra living space or private guest quarters.
Included Benefits with Every Plan
- CAD + PDF Files: Easily editable, printable, and ready for construction.
- Unlimited Build License: Build the plan multiple times at no extra cost.
- Free Foundation Changes: Choose slab, crawlspace, or basement at no charge. Learn more.
- Structural Engineering Included: Professionally reviewed and code-compliant.
- Lower Modification Costs: Our rates are up to 50% less than competitors.
- View Before You Buy: Preview all blueprint sheets in advance.
Similar Collections You Might Love
- Plans with Screened Porches
- House Plans with Bonus Rooms
- Jack and Jill Bathroom Plans
- 4 Bedroom House Plans
- Plans with Main-Level Owner Suites
Frequently Asked Questions
Does this plan include both CAD and PDF files? Yes. You’ll receive editable CAD files and print-ready PDFs for ultimate flexibility.
Can I build this house multiple times? Absolutely. Every plan comes with an unlimited-build license at no additional cost.
What if I need to change the foundation type? We offer free foundation swaps—choose from slab, crawlspace, or basement options.
Is the screened porch included? Yes! This blueprint includes both the screened porch and rear patio designs.
Can I modify this plan? Yes—modifications are fast and affordable. Request a quote today.
What makes this ranch design unique? The 1.5-story layout, bonus room with bath, and flexible bedroom configurations make it ideal for growing families or multigenerational living.
Start Building Your Dream Home Today
Have questions or want to customize this plan to suit your needs? Contact our expert team at [email protected] or use our contact form.
Your future starts with a beautifully designed house—customize this CAD floor plan and build confidently today!
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
Unless shown, the plan will not have the electrical layout. We can provide electrical layouts at $100 for 0-1499 sq. ft. home plans and $200 for 1500+ sq. ft. plans. This includes details such as recessed lights, fan/lights, switches, outlets, cable tv & telephone locations, exterior flood light locations, weather proof outlets, heat/vent/light locations…etc. After you receive the electrical layouts, review and mark any desired changes. Take a picture and we will make any and all modifications at NO EXTRA CHARGE. And do not worry if you need to go back and forth a few times. This is inclusive of the $200 fee. Turnaround time averages 2 days.
Architectural or Engineering Stamp – handled locally if required
Site Plan
Mechanical Drawings (location of heating and air equipment and duct work) – your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) – your subcontractors handle this
HVAC PLANS are not shown on the blueprints. HVAC system information regarding location of units, what types of units are used, and the duct layout are schematic only and should discuss with your local builder, mechanical (HVAC) contractor, and plumbing contractor. They should be able to provide you with the necessary information based on what your local building codes will allow.
Energy calculations – handled locally when required
Receive a modification estimate within a 24 hours. Our modification team is ready to help you adjust any plan to fit your needs. The modification process is simple and estimates are free!
1. Send photos of markups and email to [email protected]
2. Want to talk to an expert? Call us at 1-800-642-8078
Note: – a sketch of the changes or the website floor plan marked up to reflect changes is a great way to convey the modifications in addition to a written list. You can simply snap a picture and upload/message us HERE.
We are faster, better, and less expensive than our competitors!
When you submit your modification request, a designer will contact you within 24 business hours with a quote.
You can have your plan redesigned in as little as 3- days!
We look forward to hearing from you!
PDF File and CAD File: $ PRICE NOTED NEXT TO ‘ADD TO CART’
PDF File Unlimited Build: $0
Unlimited Build License issued on PDF File Unlimited Build orders.
CAD File: $0
Single Build License issued on CAD File orders.
CAD File Unlimited Build: $0
Unlimited Build License issued on CAD File Unlimited Build orders.
Right Reading Reverse/Mirrored Vertically: $0
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
Mirrored Horizontally: $0
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
Available Foundation Types: See product photos for the foundation type included with the plan. Substituting for a mono slab, stem-wall, or crawl is free of charge.
12-2210 HOME PLAN
WHAT’S INCLUDED IN THE DELIVERY
BOTH a PDF and CAD file are sent to the email provided.
PDF – Can easily be printed at nearby printing store
CAD Files – Delivered as Autocad format. These are NECESSARY for required structrual engineering. Also very helpful for any modifications.
Plans purchased are for “unlimited” or a multi-use license
*Delivered plans are identical to the product images. With most plans, additional details and notes not pictured are also included. If you wish to inquire of these notes/details, please click “Make an Enquiry for this Product” for more information.
DISCLAIMER
