Craftsman Ranch Home Plan with Vaulted Ceilings and Open Floor Design

Explore this charming 1, 710 sq. ft. single-story Craftsman Ranch house plan with 3 bedrooms, 2 baths, a spacious floor layout, and detailed CAD blueprints.

This Craftsman-style ranch house plan offers a perfect mix of comfort and functionality. Designed for modern living, it delivers timeless charm and smart space planning.

Key Features of the Home Plan

Living Areas – Heated & Unheated

  • Heated area: 1, 710 sq. ft. across a single story.
  • Unheated extras: Covered front porch, screened rear porch, and carport.

Bedrooms & Bathrooms

  • 3 comfortable bedrooms, including a first-floor Owner Suite with a walk-in closet.
  • 2 full bathrooms with easy access and privacy in mind.

Interior Highlights

  • Vaulted ceilings in the living area create volume and elegance.
  • Open floor plan enhances flow between kitchen, dining, and living spaces. View more open plans.
  • Kitchen island with walk-in pantry and breakfast nook for effortless meal prep and storage.
  • Cozy fireplace in the living room adds charm. Explore fireplace layouts.

Garage & Storage Details

  • Garage Bays: Covered carport suitable for 1 vehicle.
  • Garage Type: Open carport attached to the side.
  • Storage: Laundry room with built-in cabinetry and utility space.

Outdoor Living Features

  • Spacious screened rear porch ideal for year-round enjoyment.
  • Welcoming covered front porch for relaxing curb appeal.
  • Brick and siding exterior enhances the timeless Craftsman look.

Architectural Style: Traditional Craftsman Ranch

This design blends timeless materials and thoughtful details—perfect for families who value character and efficiency in one package. Learn more about the Craftsman architectural style or explore its roots on ArchDaily.

Bonus Features

  • Breakfast nook for casual meals and morning routines
  • Walk-in pantry keeps your kitchen organized and efficient
  • Carport adds practical vehicle protection without a bulky garage

Included Benefits with Every Plan

  • CAD + PDF Files: Easily editable, printable, and ready to build.
  • Unlimited Build License: Build once—or 100 times—with no extra fees.
  • Free Foundation Changes: Swap between slab, crawlspace, or basement.
  • Structural Engineering Included: Code-compliant and professionally stamped.
  • Lower Modification Costs: Up to 50% less than competitors.
  • View Before You Buy: See every sheet in advance.

Similar Collections You Might Love

Frequently Asked Questions

What’s included with this house plan? All plans come with editable CAD files, printable PDFs, unlimited-build rights, structural engineering, and free foundation changes.
Can I customize the layout? Absolutely! Modifications are quick and affordable. Get a custom quote.
Is this home suitable for all ages? Yes. The single-story design is accessible for all family members, including aging adults and children.
How many square feet is this home? The home features 1, 710 heated sq. ft. with additional unheated porch and carport areas.
Can I preview what’s included? Yes. View the full plan before purchasing.

Start Building Your Dream Home Today

Have questions or want to personalize your plan? Contact our expert team at [email protected] or fill out our contact form.

Your dream house starts here—customize it and build with confidence!
