Charming 2-Story Coastal Home Plan with 4 Bedrooms & Breezy Architecture
Discover this 2, 664 sq. ft. coastal house plan with 4 bedrooms, 3.5 baths, open floor plan, and CAD architecture—designed for relaxed waterfront living.
This Coastal Home Plan offers the perfect blend of beach-friendly charm and functional design. With expansive porches, an airy layout, and professionally engineered blueprints, this plan is ideal for families building near the coast or on sloping hilltop lots.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 2, 664 sq. ft. across two spacious levels.
- Unheated extras: Covered porches, balconies, and garage/workshop spaces.
Bedrooms & Bathrooms
- 4 bedrooms including a main-level Owner Suite with ensuite bath and walk-in closet.
- 3.5 bathrooms providing both private and shared access, perfect for guests and families.
Interior Highlights
- Open floor plan with seamless flow between kitchen, dining, and living areas. Explore open layouts.
- Vaulted ceilings and tall windows bring in natural light and enhance spaciousness.
- Large kitchen island, breakfast nook, and walk-in pantry for everyday function and hosting. View island kitchen plans.
- Bonus room for a home office, gym, or playroom—flexible for your lifestyle.
Garage & Storage Details
- Garage Bays: 2-car garage with adjacent workshop for tools, hobbies, or storage.
- Garage Type: Pier foundation design ideal for coastal and flood-prone regions.
- Storage: Built-in closets, large laundry with pantry extension, and attic access.
Outdoor Living Features
- Covered front and rear porches perfect for ocean breezes and outdoor gatherings. See covered porch ideas.
- Private balcony for sun-soaked relaxation or scenic water views.
- Shingle and vinyl exterior—both stylish and low maintenance for humid climates.
Architectural Style: Coastal Cottage
This design blends natural coastal materials, open-air elements, and functional coastal architecture. Learn more about the Coastal House Plan style or explore global inspirations on ArchDaily.
Bonus Features
- Flex Room: Adaptable space for remote work, fitness, or a guest suite.
- Elevated Pier Foundation: Perfect for waterfront lots or flood zones.
- Balcony & Breezy Overhangs: Add charm while keeping the home cool.
Included Benefits with Every Plan
- CAD + PDF Files: Editable, printable, and ready for your contractor.
- Unlimited Build License: Build once—or multiple times—without added fees.
- Free Foundation Changes: Customize to slab, crawlspace, or pier options.
- Structural Engineering Included: Professionally stamped for safety and code compliance.
- Lower Modification Costs: Save up to 50% vs. competitors on design changes.
- View Before You Buy: Preview every plan sheet in advance.
Similar Collections You Might Love
- Coastal House Plans
- Narrow Lot House Plans
- Plans with First Floor Owner Suites
- House Plans with Balconies
- Outdoor Living House Plans
Frequently Asked Questions
Can this plan be built on the beach? Yes! The elevated pier foundation and durable materials make it ideal for beach or flood-prone areas.
Is the Owner Suite on the first floor? Yes, the Owner Suite is located on the main level for maximum privacy and accessibility.
Are CAD files included? Absolutely—all purchases come with editable CAD and PDF files.
How large are the porches? The front and rear porches span nearly the full width of the home—perfect for coastal views.
Can I add a pool or outdoor kitchen? Yes! The layout allows for seamless outdoor upgrades like pools, patios, or kitchens. Contact us to customize.
Start Building Your Dream Home Today
Have questions or want to personalize your coastal floor plan? Reach out to our friendly design team at [email protected] or send us a quick message.
Your dream coastal house starts with this plan—relax, design, and build with confidence!
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
Unless shown, the plan will not have the electrical layout. We can provide electrical layouts at $100 for 0-1499 sq. ft. home plans and $200 for 1500+ sq. ft. plans. This includes details such as recessed lights, fan/lights, switches, outlets, cable tv & telephone locations, exterior flood light locations, weather proof outlets, heat/vent/light locations…etc. After you receive the electrical layouts, review and mark any desired changes. Take a picture and we will make any and all modifications at NO EXTRA CHARGE. And do not worry if you need to go back and forth a few times. This is inclusive of the $200 fee. Turnaround time averages 2 days.
