Ranch house Floor Plan: 3-Bed, 2-Bath CAD Designs
Explore this Ranch-style house blueprint with 3 bedrooms, 2 baths, open floor plan, CAD designs, and architecture perfect for small families and builders.
Original price was: $1,150.56.$651.99Current price is: $651.99.
999 in stock
| Width | 49'-0" |
|---|---|
| Depth | 39'-6" |
| Htd SF | |
| Unhtd SF | |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| Htd SF Range | |
| Unhtd SF Range | |
| # Garage Bays | |
| Architectural Styles | |
| Indoor Features | Bedrooms on the First Floor, Family Room, Living Room, Open Floor Plan |
| Outdoor Features | |
| Bed and Bath Features | Bedrooms on First Floor, Owner's Suite on First Floor, Walk-in Closet |
| Kitchen Features | |
| Garage Features | |
| Ceiling Features | |
| Structure Type | |
| Exterior Material | |
| # Front Elevations | |
| Depth Range | |
| Width Range | |
| After Build Photos |
Ranch Home Floor Plan: 3-Bed, 2-Bath CAD Designs
Explore this Ranch-style home blueprint with 3 bedrooms, 2 baths, open floor plan, CAD designs, and architecture perfect for small families and builders.
This Ranch-style house plan offers a perfect mix of comfort and functionality. Designed for modern living, it delivers timeless charm and smart space planning.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 1, 371 sq. ft. over a single-story design.
- Unheated extras: 574 sq. ft. including porches and 2-car garage.
Bedrooms & Bathrooms
- 3 well-sized bedrooms with all on the main level for easy access.
- 2 full bathrooms placed conveniently for privacy and function.
Interior Highlights
- Open floor plan connects kitchen, dining, and living areas. View open layouts.
- Owner suite features a walk-in closet and private bath.
- Spacious family room for relaxing or entertaining guests.
- Efficient kitchen layout ideal for small households.
Garage & Storage Details
- Garage Bays: 2-car garage with front entry.
- Garage Type: Attached garage design.
- Storage: Closets and utility areas provide ample storage.
Outdoor Living Features
- Covered front porch offers a charming and shaded entrance.
- Back deck perfect for outdoor dining or weekend relaxation.
Architectural Style: Ranch
This design blends traditional ranch charm with thoughtful, efficient layout—perfect for couples, small families, or retirees seeking accessible, one-level living. Learn more about the Ranch house style or explore its roots on ArchDaily.
Bonus Features
- Covered entry for curb appeal and guest comfort
- Compact footprint suitable for narrow or urban lots
- Simple roofline for budget-friendly construction
Included Benefits with Every Plan
- CAD + PDF Files: Easily editable, printable, and ready to build.
- Unlimited Build License: Build once—or many times—at no extra cost.
- Free Foundation Changes: Choose slab, crawlspace, or basement.
- Structural Engineering Included: Professionally stamped for peace of mind.
- Lower Modification Costs: Our updates cost up to 50% less than competitors.
- View Before You Buy: Preview all sheets in advance.
Similar Collections You Might Love
- Narrow Lot House Plans
- Simple House Plans
- Plans with Main Floor Bedrooms
- Covered Porch House Plans
- Affordable House Plans
Frequently Asked Questions
Is this home design suitable for a first-time build? Yes, this compact and affordable design is ideal for first-time builders or smaller lots.
What’s included in the plan purchase? Every plan comes with full CAD files, printable PDFs, structural engineering, and foundation flexibility.
Can I see the floor plan before purchasing? Absolutely—you can view every sheet before you buy.
Does this home include outdoor spaces? Yes! A covered porch in the front and a back deck in the rear offer excellent outdoor living areas.
Can I modify the number of bedrooms? Yes, we can help you customize the layout. Request a modification here.
Start Building Your Dream Home Today
Have questions or want to personalize your plan? Contact our expert team at [email protected] or fill out our form.
Your future house starts with a great plan—customize it and build with confidence!
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
