Craftsman Home Floor Plan – CAD Blueprint for Modern Designs
Discover this 1.5-story Craftsman-style home plan with 3 bedrooms, 2 baths, an open floor plan, and detailed CAD blueprints—perfect for modern architecture lovers.
This Craftsman-style house plan offers the perfect blend of traditional charm and modern functionality. Designed with family living and smart space planning in mind, this layout combines comfort and efficiency in a timeless architectural package.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: Approximately 1.5 stories of well-planned living space.
- Unheated extras: Front and rear porches, and a 2-car garage.
Bedrooms & Bathrooms
- 3 spacious bedrooms including a convenient first-floor Owner Suite with a walk-in closet.
- 2 full bathrooms for family and guest comfort.
Interior Highlights
- Great Room offers an inviting, open space for entertaining and everyday living.
- Fireplace creates a cozy atmosphere. See more fireplace plans.
- Open floor plan connects the living, kitchen, and dining areas. Explore open layouts.
- Kitchen island and breakfast nook deliver daily convenience and casual dining options.
- First-floor laundry room enhances everyday functionality.
Garage & Storage Details
- Garage Bays: 2-car garage with a front-entry orientation.
- Garage Type: Attached for quick and easy access.
- Storage: Walk-in closets (WIC) and practical mudroom storage.
Outdoor Living Features
- Covered front porch for relaxing and curb appeal.
- Covered rear porch perfect for outdoor dining or evening lounging.
- Exterior design with brick and siding finishes for classic Craftsman aesthetics.
Architectural Style: Traditional Craftsman
This design blends timeless materials and practical details—perfect for homeowners who value aesthetics and utility. Learn more about the Craftsman style or explore its origins at ArchDaily.
Bonus Features
- Flex space that can serve as an office, guest room, or hobby area.
- Energy-efficient layout ideal for various climates.
Included Benefits with Every Plan
- CAD + PDF Files: Easily editable, printable, and ready for permits or contractors.
- Unlimited Build License: Build this plan multiple times without paying extra fees.
- Free Foundation Changes: Customize for slab, crawlspace, or basement at no charge. See foundation options.
- Structural Engineering Included: Professionally stamped and code-compliant drawings.
- Lower Modification Costs: Save up to 50% on changes vs. competitors. Learn more about plan customization.
- View Before You Buy: Preview all sheets before purchase.
Similar Collections You Might Love
- Traditional House Plans
- Narrow Lot House Plans
- Plans with First Floor Owner Suites
- Plans with Kitchen Islands
- Covered Porch House Plans
Frequently Asked Questions
What’s included with this house plan? You receive editable CAD files, printable PDFs, unlimited-build rights, structural engineering, and free foundation adjustments.
Can I make custom changes? Yes, we offer low-cost modifications. Request a quote here.
Is this layout good for narrow lots? Absolutely. Its compact footprint and front-entry garage make it ideal for tight or city lots.
How many floors does this plan have? This is a 1.5-story layout with the Owner Suite on the main level.
Can I preview the blueprints before purchase? Yes! Preview every page here.
Start Building Your Dream Home Today
Have questions or need help tailoring the design to your needs? Reach out to our team at [email protected] or contact us online.
Turn your vision into reality—get started with a professionally engineered plan today!
Original price was: $1,582.56.$896.79Current price is: $896.79.
999 in stock
| Width | 40'-8" |
|---|---|
| Depth | 65'-2" |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| # Garage Bays | |
| Architectural Styles | |
| Indoor Features | Bedrooms on the First Floor, Downstairs Laundry Room, Fireplace, Great Room, Open Floor Plan |
| Outdoor Features | |
| Bed and Bath Features | Bedrooms on First Floor, Owner's Suite on First Floor, Walk-in Closet |
| Kitchen Features | |
| Garage Features | |
| Ceiling Features | |
| Structure Type | |
| Exterior Material | |
| # Front Elevations | |
| Depth Range | |
| Width Range | |
| After Build Photos |
8 FT+ Ceilings | Bedrooms on the First Floor | Breakfast Nook | Contemporary | Covered Front Porch | Covered Rear Porches | Craftsman | Downstairs Laundry Room | Fireplaces | First-Floor Bedrooms | Front Entry | Great Room | Kitchen Island | Living Space | Open Floor Plan Designs | Owner’s Suite on the First Floor | Traditional | Walk-in Closet
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
Unless shown, the plan will not have the electrical layout. We can provide electrical layouts at $100 for 0-1499 sq. ft. home plans and $200 for 1500+ sq. ft. plans. This includes details such as recessed lights, fan/lights, switches, outlets, cable tv & telephone locations, exterior flood light locations, weather proof outlets, heat/vent/light locations…etc. After you receive the electrical layouts, review and mark any desired changes. Take a picture and we will make any and all modifications at NO EXTRA CHARGE. And do not worry if you need to go back and forth a few times. This is inclusive of the $200 fee. Turnaround time averages 2 days.
Architectural or Engineering Stamp – handled locally if required
Site Plan
Mechanical Drawings (location of heating and air equipment and duct work) – your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) – your subcontractors handle this
HVAC PLANS are not shown on the blueprints. HVAC system information regarding location of units, what types of units are used, and the duct layout are schematic only and should discuss with your local builder, mechanical (HVAC) contractor, and plumbing contractor. They should be able to provide you with the necessary information based on what your local building codes will allow.
Energy calculations – handled locally when required
Receive a modification estimate within a 24 hours. Our modification team is ready to help you adjust any plan to fit your needs. The modification process is simple and estimates are free!
1. Send photos of markups and email to [email protected]
2. Want to talk to an expert? Call us at 1-800-642-8078
Note: – a sketch of the changes or the website floor plan marked up to reflect changes is a great way to convey the modifications in addition to a written list. You can simply snap a picture and upload/message us HERE.
We are faster, better, and less expensive than our competitors!
When you submit your modification request, a designer will contact you within 24 business hours with a quote.
You can have your plan redesigned in as little as 3- days!
We look forward to hearing from you!
PDF File and CAD File: $ PRICE NOTED NEXT TO ‘ADD TO CART’
PDF File Unlimited Build: $0
Unlimited Build License issued on PDF File Unlimited Build orders.
CAD File: $0
Single Build License issued on CAD File orders.
CAD File Unlimited Build: $0
Unlimited Build License issued on CAD File Unlimited Build orders.
Right Reading Reverse/Mirrored Vertically: $0
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
Mirrored Horizontally: $0
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
Available Foundation Types: See product photos for the foundation type included with the plan. Substituting for a mono slab, stem-wall, or crawl is free of charge.
9-1835 HOME PLAN
WHAT’S INCLUDED IN THE DELIVERY
BOTH a PDF and CAD file are sent to the email provided.
PDF – Can easily be printed at nearby printing store
CAD Files – Delivered as Autocad format. These are NECESSARY for required structrual engineering. Also very helpful for any modifications.
Plans purchased are for “unlimited” or a multi-use license
*Delivered plans are identical to the product images. With most plans, additional details and notes not pictured are also included. If you wish to inquire of these notes/details, please click “Make an Enquiry for this Product” for more information.
