Elegant house Floor Plan in CAD with Blueprint Designs
This elegant house floor plan features 5 bedrooms, 5+ baths, vaulted ceilings, and traditional architecture designs. Explore this spacious CAD blueprint plan now!
11 FT+ Ceilings | Balconies | Basement | Bonus Rooms | Breakfast Nook | Covered Front Porch | Covered Rear Porches | Designer Favorite | Downstairs Laundry Room | European | Fireplaces | First-Floor Bedrooms | Foyer | Front Entry | Great Room | Jack and Jill | Kitchen Island | Large | Living Room | Office/Study | Oversized | Owner’s Suite on the First Floor | Sloped Lot | Southern | Split Bedroom | Terrace | Traditional | Traditional Craftsman | Vaulted Ceiling | Walk-in Closet | Walk-in Pantry
Original price was: $679.60.$271.84Current price is: $271.84.
999 in stock
| Width | 96'-4" |
|---|---|
| Depth | 91'-4" |
| Htd SF | |
| Unhtd SF | |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| Htd SF Range | |
| Unhtd SF Range | |
| # Garage Bays | |
| Architectural Styles | |
| Indoor Features | Basement, Bonus Room, Downstairs Laundry Room, Fireplace, Foyer, Great Room, Living Room, Office/Study |
| Outdoor Features | |
| Bed and Bath Features | Bedrooms on First Floor, Jack and Jill Bathroom, Owner's Suite on First Floor, Split Bedrooms, Walk-in Closet |
| Kitchen Features | |
| Garage Features | |
| Ceiling Features | |
| Structure Type | |
| Exterior Material | |
| # Front Elevations | |
| Depth Range | |
| Width Range | |
| After Build Photos |
Elegant house Floor Plan in CAD with Blueprint Designs
This elegant house floor plan features 5 bedrooms, 5+ baths, vaulted ceilings, and traditional architecture designs. Explore this spacious CAD blueprint plan now!
Elegant house Floor Plan: A Modern Blueprint for Spacious Living
A Unique Blend of Tradition and Functionality
Designing your dream house starts with the perfect floor plan. Highlighting this 5, 000 sq. ft. luxury house blueprint, this design is ideal for those seeking a spacious and elegant living space. The 1.5-story layout offers a combination of practicality and beauty, with features like a first-floor Owner suite and split bedrooms for unparalleled privacy. The attention to detail in this architectural design will appeal to families, architects, designers, and builders alike.
Interior Highlights
This beautiful house boasts a blend of modern luxury and classic craftsmanship. From the moment you step inside, you’ll find features designed to enhance your lifestyle:
* Vaulted ceilings: Elevate the space with grandeur and sophistication.
* 5 bedrooms and 5+ bathrooms: Perfect for growing families or hosting guests.
* Owner suite with walk-in closet: Enjoy first-floor privacy with a luxurious touch.
* Office/study and bonus rooms: Versatile spaces tailored to your lifestyle.
* Great room and fireplace: Perfect for family gatherings and cozy evenings.
* Spacious kitchen: Includes a walk-in pantry, breakfast nook, and central kitchen island.
With well-planned spaces such as downstairs laundry and an expansive foyer, this house combines luxurious details with functional convenience.
Outdoor Benefits
This house not only shines indoors but also offers exceptional outdoor living spaces:
* Covered front and rear porches: Ideal for entertaining or relaxing year-round.
* Balcony and terrace: Dramatic additions perfect for enjoying scenic views.
* European-style brick and stone exterior: Adds timeless curb appeal.
The house is optimized for hilly or sloped lots and includes a three-car garage to accommodate vehicles and storage.
Why Choose This Plan?
Crafted in CAD for precision, this floor plan includes detailed blueprints for easy customization and construction. With 11ft+ vaulted ceilings and luxury amenities, it delivers a blend of elegance and functionality. Whether you’re an architect designing for a client or a family building their forever house, this Traditional Craftsman-style plan offers everything you need.
Benefits Included with Our Plans
With every house floor plan, you’ll receive the CAD file and PDF blueprints, complete with an unlimited-build license. All plans include free foundation customization and structural engineering to save time and money. Additionally, our modification services are available at competitively lower costs compared to others in the industry.
Take the first step toward your design dreams! Contact [email protected] for inquiries or to customize this remarkable architectural gem into your very own dream house today.
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
Unless shown, the plan will not have the electrical layout. We can provide electrical layouts at $100 for 0-1499 sq. ft. home plans and $200 for 1500+ sq. ft. plans. This includes details such as recessed lights, fan/lights, switches, outlets, cable tv & telephone locations, exterior flood light locations, weather proof outlets, heat/vent/light locations…etc. After you receive the electrical layouts, review and mark any desired changes. Take a picture and we will make any and all modifications at NO EXTRA CHARGE. And do not worry if you need to go back and forth a few times. This is inclusive of the $200 fee. Turnaround time averages 2 days.
