Luxury house Floor Plan with 2 Stories and CAD Designs
Explore a luxury 2-story house plan with detailed CAD blueprints. Features 5 bedrooms, 5+ bathrooms, vaulted ceilings, and open floor plans for modern designs.
Luxury 2-Story House Plan with Vaulted Ceilings & Open Layout
Explore this luxury house blueprint featuring 5, 774 heated sq. ft., 5 bedrooms, 5+ baths, and CAD-ready designs—perfect for elegant, spacious living.
This luxury house plan offers a perfect mix of comfort and functionality. Designed for modern living, it delivers timeless charm and smart space planning.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 5, 774 sq. ft. over two expansive stories.
- Unheated extras: Includes a 3-car side-entry garage, covered porches, and ample storage areas.
Bedrooms & Bathrooms
- 5 total bedrooms including a private first-floor Owner Suite with dual vanities and a large walk-in closet.
- 5+ bathrooms, including a convenient Jack and Jill bath upstairs and en-suites for added luxury.
Interior Highlights
- Vaulted ceilings throughout enhance space and natural light.
- Open floor plan seamlessly integrates the family room, kitchen, and living area. View open layouts.
- Gourmet kitchen with a large island, walk-in pantry, and breakfast nook—perfect for entertaining. Browse gourmet kitchens.
- Dedicated spaces include a home cinema, formal study, and mudroom with built-ins.
- Upstairs laundry room offers everyday convenience.
Garage & Storage Details
- Garage Bays: 3-car garage with side entry for a clean front elevation.
- Garage Type: Attached, traditional Craftsman-style with room for tools or a workshop.
- Storage: Features include attic access, linen closets, and dedicated mudroom cubbies.
Outdoor Living Features
- Enjoy a covered front porch for welcoming guests or relaxing evenings.
- Screened porch offers bug-free comfort all year.
- Covered rear porch is ideal for grilling, hosting, or quiet retreats. Explore porch plans.
- Exterior finishes include brick, shake, siding, shingles, and stone for long-lasting curb appeal.
Architectural Style: Traditional Meets Modern Craftsman
This design blends timeless materials and thoughtful details—perfect for families who value character and efficiency in one package. Learn more about the Traditional Craftsman style or explore its roots on ArchDaily.
Bonus Features
- Home cinema for ultimate entertainment experiences.
- Study/home office for quiet productivity.
- Jack and Jill bath design offers efficient privacy for shared bedrooms.
Included Benefits with Every Plan
- CAD + PDF Files: Easily editable, printable, and ready to build.
- Unlimited Build License: Build once—or 100 times—with no extra fees.
- Free Foundation Changes: Swap between slab, crawlspace, or basement.
- Structural Engineering Included: Code-compliant and professionally stamped.
- Lower Modification Costs: Up to 50% less than competitors.
- View Before You Buy: See every sheet in advance.
Similar Collections You Might Love
- Luxury House Plans
- 5-Bedroom House Plans
- Plans with Kitchen Islands
- Owner Suite on Main Floor Plans
- Screened Porch House Plans
Frequently Asked Questions
How many stories does this luxury house have? It’s a 2-story design with a grand main level and a private upper floor.
Can I make changes to the layout? Yes! We offer affordable customization services. Request a quote here.
Are CAD files included? Absolutely. You’ll receive both CAD and printable PDF files.
Does this come with structural engineering? Yes—every plan includes professional structural engineering.
Is this plan available with a screened porch? Yes, it includes a screened porch at the rear for all-season outdoor comfort.
Start Building Your Dream Home Today
Have questions or want to personalize your plan? Contact our expert team at [email protected] or fill out our form.
Your future house starts with a great plan—customize it and build with confidence!
Shortcode is running ✓
Preview: Luxury 2-Story House Plan with Vaulted Ceilings & Open Layout Explore this luxury house blueprint featuring 5,774 heated sq. ft., 5 bedrooms, 5+ baths, and CAD-ready designs—perfect for elegant, spacious living. This luxury house plan offers a perfect mix of comfort and functionality. Designed…
Read MoreOriginal price was: $2,878.56.$1,631.19Current price is: $1,631.19.
999 in stock
| Width | 73'-0" |
|---|---|
| Depth | 83'-6" |
| Htd SF | |
| Unhtd SF | |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| Htd SF Range | |
| Unhtd SF Range | |
| # Garage Bays | |
| Architectural Styles | |
| Indoor Features | Family Room, Foyer, Home Cinema, Living Room, Mudroom, Open Floor Plan, Study, Upstairs Laundry Room |
| Outdoor Features | |
| Bed and Bath Features | Jack and Jill Bathroom, Owner's Suite on First Floor, Walk-in Closet |
| Kitchen Features | |
| Garage Features | |
| Ceiling Features | |
| Structure Type | |
| Exterior Material | |
| # Front Elevations | |
| Depth Range | |
| Width Range | |
| After Build Photos |
10 FT+ Ceilings | Breakfast Nook | Builder Favorites | Covered Front Porch | Covered Rear Porches | Editor's Pick | Family Room | Foyer | Home Cinema | Home Plans with Mudrooms | Jack and Jill | Kitchen Island | Living Room | Luxury | Modern Craftsman | Open Floor Plan Designs | Owner’s Suite on the First Floor | Screened Porches | Side Entry Garage | Study | Traditional | Upstairs Laundry Room | Vaulted Ceiling | Walk-in Closet | Walk-in Pantry
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
