Luxury Home Design with Floor Plan Blueprint and CAD Features
Discover this stunning CAD and blueprint floor plan design. This beautiful 2-story home offers 4 bedrooms, 4 baths, and exceptional indoor and outdoor features.
Explore This Elegant Home Design
If you're looking for a thoughtfully designed home plan, this stunning CAD blueprint offers a perfect balance of warmth and modern convenience. This 2-story home features 4 bedrooms, 4 bathrooms, and an array of unique architectural elements to make it your dream residence. With a width of 58′-6″ and a depth of 64′-6″, this home provides ample space without sacrificing elegance.
Indoor Features
Inside, this home quickly captures attention with its practical floor plan and luxurious indoor spaces. The main floor boasts an owner's suite with a walk-in closet and a private bathroom, ensuring comfort and privacy. The open floor plan connects the great room, dining room, and kitchen, encouraging seamless flow for gatherings. Additional highlights include:
* Recreational Room for entertainment options.
* Cozy great room for family time or relaxing evenings.
* Mudroom and laundry room to make daily chores convenient.
* Butler's Pantry and kitchen island in the ultimate kitchen.
* Split bedrooms feature a Jack and Jill layout for added functionality.
Outdoor and Structural Features
The home's exterior architecture blends brick, shingles, and shake elements, creating a timeless and stylish appearance. Outdoor spaces include a covered front porch, a rear porch, and an inviting patio perfect for relaxation or entertaining. The side-entry garage accommodates two cars while maintaining the home's clean facade.
For those who love functionality paired with visual appeal, the 9ft+ beamed ceilings and luxurious kitchen features deliver unmatched versatility.
Foundation and Material
Designed with a crawlspace foundation, this home's structural setup minimizes maintenance challenges. Its traditional, country, and craftsman styles reflect sophistication while staying grounded in comfort.
Benefits Included with Every Plan
Every home design comes with more than just a beautiful blueprint. CAD and PDF files are included in your purchase, along with options for unlimited builds. We also provide free foundation updates and structural engineering, ensuring your design is both stylish and secure.
Ready to Build Your Dream Home?
Are you ready to bring your dream home plan to life? Contact us at support@https://myhomefloorplans.com to explore customizations or to begin building today!
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
Unless shown, the plan will not have the electrical layout. We can provide electrical layouts at $100 for 0-1499 sq. ft. home plans and $200 for 1500+ sq. ft. plans. This includes details such as recessed lights, fan/lights, switches, outlets, cable tv & telephone locations, exterior flood light locations, weather proof outlets, heat/vent/light locations…etc. After you receive the electrical layouts, review and mark any desired changes. Take a picture and we will make any and all modifications at NO EXTRA CHARGE. And do not worry if you need to go back and forth a few times. This is inclusive of the $200 fee. Turnaround time averages 2 days.
