A Luxurious 5, 500 Sq. Ft. Tudor-Style house Plan with Detailed CAD Blueprints
This stunning Tudor-style house plan features 5, 500 heated sq. ft., 4 bedrooms, 5+ bathrooms, detailed CAD designs, open floor plans, and premium outdoor features.
10 FT+ Ceilings | Basement | Beamed | Breakfast Nook | Butler’s Pantry | Coffered | Covered Deck | Covered Front Porch | Downstairs Laundry Room | European | Fireplaces | First-Floor Bedrooms | Foyer | Great Room | Kitchen Island | Luxury | Office/Study | Open Floor Plan Designs | Owner’s Suite on Second Floor | Owner’s Suite on the First Floor | Patios | Recreational Room | Screened Porches | Second Floor Bedroom | Side Entry Garage | Sloped Lot | Traditional | Tudor | Two Owner's Suites | Ultimate Kitchen | Uncovered Deck | Vaulted Ceiling | Walk-in Closet | Walk-in Pantry | Workshop
Original price was: $3,598.56.$2,039.19Current price is: $2,039.19.
999 in stock
| Width | 88'-0" |
|---|---|
| Depth | 53'-0" |
| Htd SF | |
| Unhtd SF | |
| Bedrooms | |
| Bathrooms | |
| # of Floors | |
| Htd SF Range | |
| Unhtd SF Range | |
| # Garage Bays | |
| Architectural Styles | |
| Indoor Features | Basement, Downstairs Laundry Room, Fireplace, Foyer, Great Room, Office/Study, Open Floor Plan, Recreational Room |
| Outdoor Features | Covered Front Porch, Covered Deck, Patio, Screened Porch, Uncovered Deck |
| Bed and Bath Features | Bedrooms on First Floor, Bedrooms on Second Floor, Owner's Suite on First Floor, Owner's Suite on Second Floor, Two Owner's Suites, Walk-in Closet |
| Kitchen Features | Breakfast Nook, Butler's Pantry, Kitchen Island, Ultimate Kitchen, Walk-in Pantry |
| Garage Features | |
| Ceiling Features | |
| Structure Type | |
| Exterior Material | |
| # Front Elevations | |
| Depth Range | |
| Width Range | |
| After Build Photos |
Luxurious Tudor-Style House Plan with 5, 500 Sq. Ft. and CAD Blueprints
Discover this grand Tudor house plan featuring 5, 500 heated sq. ft., 4 bedrooms, 5+ baths, open floor layout, and premium architectural CAD designs.
This Tudor-style house plan offers the perfect blend of historic elegance and modern convenience. With spacious interiors and a beautifully detailed layout, it’s an ideal choice for large families and those seeking architectural sophistication.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 5, 500 sq. ft. across 2.5 stories.
- Unheated extras: Covered front porch, screened rear patio, deck, and 3-car garage with workshop space.
Bedrooms & Bathrooms
- 4 spacious bedrooms including dual Owner Suites—one on each floor for maximum flexibility and privacy.
- 5+ bathrooms designed for convenience, with en-suite access and elegant finishes.
Interior Highlights
- Vaulted and coffered ceilings add visual drama and volume to living spaces.
- Open floor plan seamlessly connects great room, kitchen, and dining. Explore open layouts.
- Ultimate kitchen includes a kitchen island, butler’s pantry, and walk-in pantry. See more with kitchen islands.
- Fireplace brings warmth and charm to the main gathering area. Browse fireplace floor plans.
- Dedicated office/study and recreation room provide spaces for work and play.
Garage & Storage Details
- Garage Bays: 3-car garage with side-entry and dedicated workshop zone.
- Garage Type: Attached, side-load—perfect for curb appeal and utility. See more side-load garage plans.
- Storage: Ample closet space in every bedroom, attic storage, mudroom, and flex-use basement areas.
Outdoor Living Features
- Covered front porch and screened patio offer year-round comfort outdoors.
- Deck and rear patio provide beautiful spaces for grilling, lounging, or dining al fresco.
- Built with a combination of brick, stone, and siding—ensuring lasting quality and timeless beauty.
Architectural Style: Tudor
This design channels classic Tudor architecture with steep-pitched gables, half-timbering accents, and a picturesque layout. It’s the perfect mix of historical character and modern livability. Learn more about the Tudor style or explore its heritage on ArchDaily.
Bonus Features
- Two Owner Suites: Ideal for multi-generational living or guest comfort.
- Basement Recreation Room: A large, finished space for games, theater, or hobbies.
- Workshop Garage Bay: Extra space for tools, DIY, or storage.
Included Benefits with Every Plan
- CAD + PDF Files: Editable and printable blueprints ready for permitting and construction.
- Unlimited Build License: Build as many times as you’d like—no added fees.
- Free Foundation Changes: Easily adapt to slab, crawlspace, or basement needs. See foundation options.
- Structural Engineering Included: Professionally stamped and ready for code compliance.
- Lower Modification Costs: Save up to 50% compared to other vendors. Customize your plan here.
- View Before You Buy: See every sheet in advance.
Similar Collections You Might Love
- Luxury House Plans
- Plans with Recreation Rooms
- Walk-in Closet House Plans
- Plans with First Floor Owner Suites
- House Plans with Patios
Frequently Asked Questions
Are both Owner Suites fully private? Yes. Each suite features a full private bathroom and walk-in closet for complete privacy and flexibility.
Can I build this plan multiple times? Absolutely. Each purchase includes an unlimited-build license at no extra charge.
Is the basement included in the heated area? No, the heated area includes the above-grade floors. The basement is additional and finished separately.
Can this plan be adapted for a flat lot? Yes. We offer free foundation customization to suit any lot.
Do I get to see everything before buying? Of course—preview every sheet before you purchase.
Start Building Your Dream Home Today
Have questions or want to personalize this floor plan? Email our team at [email protected] or reach out here.
Design your future with confidence—our detailed blueprints make building a breeze!
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
