Elegant 5-Bedroom House Plan with Traditional Design and CAD Blueprints
Discover this spacious 3, 436 sq. ft. traditional-style house plan with 5 bedrooms, 3.5 baths, open layout, and 2.5 stories—includes CAD files and architectural designs.
This traditional house plan offers a perfect mix of comfort and functionality. Designed for modern families, it delivers timeless charm and smart space planning.
Key Features of the Home Plan
Living Areas – Heated & Unheated
- Heated area: 3, 436 sq. ft. over 2.5 stories.
- Unheated extras: Includes 1, 648 sq. ft. of garage, attic storage, porches, and patio space.
Bedrooms & Bathrooms
- 5 spacious bedrooms including a second-floor Owner Suite with a large walk-in closet.
- 3.5 bathrooms designed for convenience and guest accessibility.
Interior Highlights
- Open floor plan seamlessly connects the great room, kitchen, and dining area. View open layouts.
- Formal dining room ideal for entertaining.
- Kitchen island, breakfast nook, and walk-in pantry provide cooking ease.
- Family room adds a secondary gathering space for relaxation or media.
Garage & Storage Details
- Garage Bays: 3-car garage offering ample parking.
- Garage Type: Attached, with direct entry into the home.
- Storage: Additional attic and flexible unheated storage areas for seasonal or overflow needs.
Outdoor Living Features
- Covered front porch for curb appeal and welcoming entry.
- Screened porch and rear patio—ideal for outdoor lounging, dining, or entertainment.
Architectural Style: Traditional
This design blends timeless materials and classic detailing—perfect for those who appreciate a blend of character and modern amenities. Learn more about the Traditional style or explore its design roots on ArchDaily.
Bonus Features
- Attic space adaptable for future expansion or storage.
- Dedicated family room and great room layout for versatility.
- Formal entry foyer provides elegant arrival experience.
Included Benefits with Every Plan
- CAD + PDF Files: Editable and printable for builders, designers, and DIY homeowners.
- Unlimited Build License: Build your dream house once or multiple times without paying more.
- Free Foundation Changes: Choose between basement, crawlspace, or slab without added cost.
- Structural Engineering Included: All plans are code-compliant and engineer-approved.
- Lower Modification Costs: Save up to 50% compared to our competitors.
- View Before You Buy: Preview every plan sheet before purchase.
Similar Collections You Might Love
- 5-Bedroom House Plans
- Traditional Farmhouse Plans
- House Plans with Attic Space
- Covered Back Porch Plans
- Plans with Walk-in Closets
Frequently Asked Questions
What makes this house plan ideal for families? With 5 bedrooms, dual living spaces, and multiple porches, it’s perfect for growing families or multigenerational households.
Can I customize the layout or number of stories? Absolutely! We offer quick and affordable customizations to suit your specific needs. Request a quote here.
Does it come with engineering and permits help? Yes—this plan includes structural engineering so you’re ready to meet local building codes.
Can I see what I’m buying? Yes! View every sheet before checkout.
Is this plan suitable for traditional neighborhoods? Definitely. The timeless architecture and flexible layout work beautifully in both suburban and urban lots.
Start Building Your Dream Home Today
Have questions or want to personalize your plan? Contact our expert team at [email protected] or fill out our contact form.
Your dream house starts here—customize it and start building with confidence!
All home plans include BOTH the CAD file and PDF file.
See the photos of the ACTUAL plan you would receive. Scales vary depending on the size of the home and paper size. *Most plans have added notes and/or details that are not shown in photos. These can include various calculations, structural and architectural details. CLICK MAKE AN ENQUIRY and we can update the product with all notes/details.
All plans are FREE for unlimited-build.
Roof plans are provided with every package. This will show all roof slopes and a roof framing detail. Miscellaneous details as needed per house plan.
Unless shown, the plan will not have the electrical layout. We can provide electrical layouts at $100 for 0-1499 sq. ft. home plans and $200 for 1500+ sq. ft. plans. This includes details such as recessed lights, fan/lights, switches, outlets, cable tv & telephone locations, exterior flood light locations, weather proof outlets, heat/vent/light locations…etc. After you receive the electrical layouts, review and mark any desired changes. Take a picture and we will make any and all modifications at NO EXTRA CHARGE. And do not worry if you need to go back and forth a few times. This is inclusive of the $200 fee. Turnaround time averages 2 days.
